Page 24
MAXX 6T Owner’s Manual
In addition, there are selections for each open transport window. Selecting one of these brings that
transport to the top of the display and makes it the active window.
Help Menu
Contains a single item, About, which displays the Image Server software versions, serial number
and Unit ID.
The Status Bar
A status bar appears at the bottom of the window that provides system information to the user
including
GENLOCK
,
INPUT VIDEO DETECTED
, and
TIME REMAINING
—
PERCENT FULL
. Messages such as
CONNECTED TO HOST
or
CONNECTION TO HOST REFUSED
are also displayed as diagnostics. Error and
status messages from the RAID system can also be displayed here.
Channel 1 is the only channel that can either Record or Play video content. Channels 2 and 3 can
play back content. All channels may be used at the same time.
Each channel can be controlled in two different views.
1. The Transport View
2. The Playlist View
