Page 112 MAXX 6T Owner’s Manual
APPENDIX C – INPUT CHANNEL FACTORY SETTINGS
The factory default settings for Input Channel Configuration are presented for reference. Most
of these video encoding options will be suitable for general broadcast operations, but may
not be optimum for contribution content, or use at low bit rates.
Input source CVBS MPEG-2 Profile 4:2:2
Track Arm GOP Structure I-FRAME
Video ON
Audio 1-2 ON BIT RATE 12 Mb/s
Audio 3-4 OFF
CC OFF
Audio Sample Rate Conversion
Tracks 1-2 OFF
Tracks 3-4 OFF
Timecode Source MANUAL
Start Time 00:00:00:00
Figure 18: Channel 1 Factory Default Settings
