SPECIFICATIONS
Pick-up System:
Image Sensor:
Pixels:
Scanning Standard:
Synchronizing System:
Video Outputs:
Required Illumination:
Minimum Illumination:
Signal-to-Noise Ratio:
Horizontal Resolution:
White Balance:
Black Balance:
Color Bar:
Electronic Shutter:
Gain Selection:
Switches:
Controls:
Computer Interface
Lens Mount:
Power Source:
Power Consumption:
Ambient Operating Temperature:
Ambient Operating Humidity:
Dimensions
Camera Head:
(Excluding Mounting Adaptor)
CCU:
(Excluding Rubber Foot and Connector) [8-1/8" (W) x 1-11/16" (H) x 9-1/2" (D)]
Weights
Camera Head: 110 g (0.24 lbs)
CCU: 1.7 kg (3.74 lbs)
Dimensions and Weights indicated are approximate
Specifications are subject to change without notice
Micro prism system
Three 1/2" interline transfer (IT) super high sensitivity CCDs (GP-US522)
Three 1/3" interline transfer (IT) super high sensitivity CCDs (GP-US532)
768 (Horizontal) x 494 (Vertical)
525 lines, 60 fields, 30 frames
Internal or External (Gen-Lock), automatically switchable
Internal: EIA standard
External (Gen-Lock) Input: VBS/VS/HD/VD is selectable
SC Phase for Gen-Lock (VBS): Free adjustable over 360°
H Phase for Gen-Lock (VS): Adjustable
Video Output: BNC Connector x 2
1.0V[p-p] NTSC composite/75 Q
Y/C (S-VIDEO) Output: S-VIDEO Connector x 1
0,714V[p-p] Luminance level (Y)/75 Q (S-VIDEO connector)
0.286V[p-p] Burst Level (C)/75 Q (S-VIDEO connector)
RGB/SYNC Output: D-SUB 9-pin Connector x 1
R/G/B;
0.7V[p-p] each/75 Q
SYNC: 4V[p-p]/75 П or 0.3V[p-p]/75 П selectable
VIDEO: NTSC composite/75
2000 lx at F11.0, 3200 К (GP-US522)
2000 lx at F8.0, 3200 К (GP-US532)
5 lx (0.5 foot candle) at F2.8 with -t-18 dB gain, 30 IRE level (GP-US522)
9 lx (0.9 foot candle) at F2.2 with -i-18 dB gain, 30 IRE level (GP-US532)
62 dB (Typical, Luminance) without aperture and gamma
800 lines at center (Y signal) (GP-US522)
750 lines at center (Y signal) (GP-US532)
ATW (Automatic Tracing White Balance Control), AWC (Automatic White
Balance Control) and Manual
ABC (Automatic Black Balance) and Manual
SMPTE color bar with 7.5% set-up
AUTO:
Adjustable between 1/60 - 1/10 000s
STEP: Selectable 1/60(OFF),1/100, 1/250, 1/500, 1/1 000, 1/2 000,
1/4 000 and 1/10 000s
SYNCHRO SCAN: Selectable from 1/525 to 254/525 line
AGC and Gain Up (Selectable)
Power On/Off (POWER), Camera/Color Bar Selection (CAM/BAR),
Gain Up Selection (OFF/LOW/HIGH (0/+9/-i-18 dB)), White Balance Selection
(ATW/AWC/MANU), ELC (Electronic Light Control) On/Off, PAGE, ITEM (AWC),
(ABC) and ►
R Gain, В Gain and ELC LEVEL
RS-232C : D-SUB 9-pin Connector x 1
Special C Mount (GP-US522)
C Mount (GP-US532)
12 V DC
8.4 W
32°F- 113°F (0°C - -ь45°С)
30 % - 90 %
34 (W) X 44 (H)x 52(D) mm
[1-5/16- (W)
X
1-11/16- (H)
X
2- (D)]
(206,5 (W) X 44 (H) X 250 (D) mm)
-
