Installation Procedures
First complete the electrical connections, and then
check them for correctness, {page 50)
(D Power
connector
Mounting
springs (^i)
Mounting holes
(D Mounting bolt
Mounting springs (
й
;)
Engage the mounting
springs (iii) in the
mounting holes of
the mounting collar
© firmly.
g—Mounting
hole
Mounting springs
(a) Using the rear support strap
®
Fire wall of car
0 Tapping screw
3 mm0
d) Hex. nut
0 Rear support
strap______
0 Mounting bolt
Mounting collar
The included mounting collar © is designed
specifically for this unit. Do not use it to attach
any other model.
Insert mounting collar © into the
dashboard, and bend the mounting tabs
out with a screwdriver.
The tabs to be bent vary depending on the
car. To securely install the unit, fully bend
a number of the tabs so that there is no
rattling.
Example:
о
о
Secure the rear of the unit.
After fixing mounting bolt 0 and power con
nector 0, fix the rear of the unit to the car
body by either method
(a)
or
(b)
shown below.
Insert trim plate
0.
After installation,
reconnect the nega
tive 0 battery ter
minal.
(b) Using the rubber cushion (option)
Rear support bracket
Rubber cushion (option) (provided on the car)
0 Mounting bolt
^ © Mounting collar
