Specifications
LCD Screen Size 15" LCD (15.0" / 38,1cm Viewable Image Size)
Type TFT Active Matrix Liquid Crystal
Pixel pitch 0.297 mm
Coiors* Equivalent of 16.19 million colors by error dispersion technology
Response Fast (23 ms (typical)) Suitable for monitor pictures.
Contrast Ratio 400 : 1 (Typical)
Viewing angle R / L: ± 70 degrees, Up: 55 degrees, Down: 70 degrees (Typical)
Surface Anti-Glare Hard coat
input signals Video signal RGB Analog (0.7 Vp-p ~ 1,0 Vp-p, 75 ohms)
Sync signal (The monitor
cannot be used in the interlaced
mode.)
H / V separate (TTL), H / V combined,
or Sync-on-Green
H-Sync 30 kHz - 61 kHz
V-Sync 50 Hz - 77 Hz
Modes 15 Factory Preset (Reservation) Modes (See page 17.)
16 User Memories (See page 16.)
Video Pixel Clock 80 MHz max.
Resolution (H X V) 1024 dots X 768 lines 75Hz N1, FCC Class B, Max.
Viewable image Size Full scan
(H X V, Diagonal)
11.97" X 8.98", 15.0" diagonal 640 x 480 to 1024 x 768
30.4 cm X 22.8 cm, 38.1 cm diagonal 640 x 480 to 1024 x 768
Connectors Display Signal One 15 pin mini D-Sub
Headphone terminal 3.5 mm diameter stereo mini jack
Audio input terminal 3.5 mm diameter stereo mini jack
USB terminals Upstream port x 1
Downstream Port x 4
Power supply CEE 22 type 3-pin connector
Power consumption On 55 Watts (typical)
(VESA DPMS, See Page 16, Stand-by < 15 Watts
Power Management System) Suspend < 15 Watts
(No USB peripherals) Off < 5 Watts
Controls Right side panel Power Switch (On / Off)
Soft Touch Front panel Menu key, Left key, Right key, - key, + key, Volume key,
Mute key, Power LED, With direct access to Brightness & Contrast
On screen display CONTRAST, BRIGHTNESS, BACKLIGHT, H. POSITION, H. SIZE,
V. FINETUNE**, V. POSITION, V. SIZE, H. FINETUNE**,
COLOR TEMP (Normal color / 9300K / User color), VIDEO LEVEL
ADJ (0.7V-1.0V), DISP. FREQ., LANGUAGE (German, French,
English, Italian, Spanish), AUTO SIZE, RECALL (Factory Settings),
OSD POSITION, PICTURE, VOLUME, MONITOR SELF-TEST
(w / NO SIGNAL Input or SIGNAL ERROR (Out of Range))
**See Page 13 and 14, Menu.
Dimensions (Net) (W x H x D) 15.16" X 15.39" X 7.88" (385 mm x 391 mm x 200 mm)
Speakers Frequency response 80 Hz to 20 kHz
Practical audio output 1 W + 1 W (typ)
Weight (Net) 7.1 kg (15.7 lbs)
Display Approvals UL1950, CSA 22.2 No. 950, TUV / GS, NORDIC,
FCC Class B, IC-B, CE / CISPR 22-B, VCCI-B,
MPR II, TCO’92 / NUTEK, IS09241-3 (Ergonomics),
E nergy S tar ®
Standard Signal Cable One 15 pin male mini D-Sub to 15-pin male mini D-Sub (4.92' 1 1.5 meters)
Power Cable One UL 3 pole (CEE 22 type) (5.91 '/1.8 meters)
Other Cables USB Cable (5.91 '/1.8 meters), USB DC Cable (0.8' / 0.241 meters)
Audio Cable (5.91 ’/1.8 meters)
Tilt Base (Removable) Tilt 0 - 30=
Documentation operating Instructions & Warranty card
Optional Mac Adapter UNIMAC - 82D (Not included)
Operating Temperature 32 to 95=F (0 to 35=0
Humidity 5% to 90% Non-condensing
Storage Temperature -4to140=F(-20 to 60=0
Humidity 5% to 90% Non-condensing
Factory Preset Reservation Modes See Pages 17 and 18.
Windows*95/ 98 Plug & Play VESA DDC1/2B (Meets Windows95 / 98 Plug & Play Requirements)
Specifications and design are subject to change without notice.
This product may be subject to export reguiations.
* Number of coiors dispiayed for a given resoiution mode depends on your video source, video memory instaiied and RAMDAC
(Random Access Memory Digitai to Anaiog Converter).
