Connecting USB Devices
Always use the USB cable that is
enclosed with the unit.
I Prepare the accessory USB cable provided.
I
Connect the USB connector (Type A) to the computer.
I
Connect the USB connector (Type B) to the USB UP stream port of the main unit.
I Connect the cable of the USB device being used to the USB DOWN stream port of
the main unit.
USB Cable
e[^)
Type A Connector
Typical Connections
Type B Connector
