Non-interlaced only
VESA 800x600 @60 Hz
Reservation timing
VESA 800 x 600 @72 Hz
VESA 800
X
600 @ 75Hz
DOT CLOCK
40.0000
MHz
50.0000
, MHz
49.5000 MHz
fH
37.8788 kHz
48.0769 kHz
46.875 kHz
A H-Period
26.400 us(1056) Dots
20.800
us(1040) Dots
21.333 us(1056) Dots
H-Blanking
6.400 us( 256) Dots
4.800 us( 240) Dots
5.171 us{ 256) Dots
H-Sync width
3.200 us( 128) Dots
2.400 us( 120) Dots
1.616 us( 80) Dots
H-Back porch
2.200 us( 88) Dots
1.280 us( 64) Dots
3.232 us( 160) Dots
D
H-Active
20.000 us( 800) Dots
16.000 us( 800) Dots
16.162 us( 800) Dots
H-Front porch
1.000
us( 40) Dots
1.120 us( 56) Dots
0.323 us( 16) Dots
fV
60.3165 Hz
72.1876 Hz
75.0000 Hz
P V-Period
16.579 ms( 628) Lines
13.853 ms( 666) Lines
13.333 ms( 625) Lines
U
V-Blanking
0.739 ms( 28) Lines
1.373 ms( 66) Lines
0.533 ms( 25) Lines
V-Sync width
0.106 nns( 4) Lines
0.125 ms( 6) Lines
0.064 ms( 3) Lines
V-Back porch
0.607 ms( 23) Lines
0.478 ms( 23) Lines
0.448 ms( 21) Lines
V-Active
15.840 ms( 600) Lines
12.480 nns( 600) Lines
12.800
ms( 600) Lines
V-Front porch
0.026 ms( 1) Line
0.770 ms( 37) Lines
0.021 ms( 1) Line
Sync polarity (HA/)
Positive / Positive
Positive / Positive
Reservation timing* *
••
Positive / Positive
Mac{16‘)832 x 624 @ 75Hz” VESA 1024 x 768 @60 Hz
VESA 1024 X768 @ 70 Hz
DOT CLOCK
57.2832 MHz
65.0000
MHz
75.0000
MHz
fH
49.7250 kHz
48.3631 kHz
56.4759 kHz
A H-Period
20.111 us(1152) Dots
20.677 us(1344) Dots
17.707 us(1328) Dots
H-Blanking
5.587 us( 320) Dots
4.923 us{ 320) Dots
4.054 us{ 304) Dots
H-Sync width
1.117 us( 64) Dots
2.092 us( 136) Dots
1.813 us( 136) Dots
H-Back porch
3.910 us( 224) Dots
2.462 us{ 160) Dots
1.920 us{ 144) Dots
H-Active
14.524 us( 832) Dots
15.754 us(1024) Dots
13.653 us(1024) Dots
H-Front porch
0.559 us( 32) Dots
0.369 us( 24) Dots
0.320 us( 24) Dots
fV
74.5502 Hz
60.0038 Hz
70.0694 Hz
P V-Period
13.414 ms( 667) Lines
16.666 ms( 806) Lines
14.272 ms( 806) Lines
U
V-Blanking
0.865 ms( 43) Lines
0.786 ms( 38) Lines
0.673 ms( 38) Lines
V-Sync width
0.060 ms( 3) Lines
0.124 ms( 6) Lines
0.106 ms( 6) Lines
V-Back porch
0.784 ms( 39) Lines
0.600 ms( 29) Lines
0.513 ms( 29) Lines
V-Active
12.549 ms( 624) Lines
15.880 ms( 768) Lines
13.599 ms( 768) Lines
V-Front porch
0.020 ms( 1) Line
0.062 ms( 3) Lines
0.053 ms( 3) Lines
Sync polarity (H / V)
Negative / Negative
Negative / Negative
Negative / Negative
VESA 1024 x 768 @72 Hz
Reservation timing
VESA 1024 x 768 @75 Hz
Mac (1901024 x 768 075 Hz"
DOT CLOCK
75.0000 MHz
78.7500 MHz
80.0000 MHz
fH
57.8703 kHz
60.0229 kHz
60.241 kHz
A H-Period
17.280 us(1296) Dots
16.660 us(1312) Dots
16.600 us(1328) Dots
H-Blanking
3.627 us( 272) Dots
3.657 us( 288) Dots
3.800 us( 304) Dots
H-Sync width
1.920 us( 144) Dots
1.219 us( 96) Dots
1.200 us( 96) Dots
H-Back porch
1.387 us( 104) Dots
2.235 us( 176) Dots
2.200 us( 176) Dots
H-Active
13.653 us(1024) Dots
13.003 us{1024) Dots
12.800 us(1024) Dots
E H-Front porch
0.320 us( 24) Dots
0.203 us{ 16) Dots
0.400 us( 32) Dots
fV
71.7978 Hz
75.0286 Hz
74.927 Hz
P V-Period
13.928 ms( 806) Lines
13.328 ms( 800) Lines
13.346 ms( 804) Lines
U
V-Blanking
0.657 ms{ 38) Lines
0.533 ms{ 32) Lines
0.597 ms( 36) Lines
V-Sync width
0.104 ms{ 6) Lines
0.050 ms{ 3) Lines
0.049 ms( 3) Lines
V-Back porch
0.501 ms{ 29) Lines
0.466 ms( 28) Lines
0.498 ms( 30) Lines
V-Active
13.271 ms{768) Lines
12.795 ms( 768) Lines
12.749 ms( 768) Lines
T V-Front porch
0.052 ms{ 3) Lines
0.017 ms{ 1) Line
0.049 ms( 3) Lines
Sync polarity {H / V) Negative / Negative
Note: All modes are Non-Interlaced.
* Factory Reservation timing have approximate size & centering.
•• Requires the use of Optionai Mac Adapter UNIMAC-82D, _ i g
Positive / Positive
Negative / Negative
