Adjustments
Menu Screen
Ttie menu screen changes to two different screens according to the screen resolution.
The menu screen is displayed by the MENU key. The adjustment items of this unit are
displayed as icons.
Each icon indicates an adjustment item shown in the figure.
When the resolution is 640 x 400 to 832 x 624
üt> B
□0 : q E3
[S lU
100
HEKU CONTRAST
c>
CONTRAST BACKLIGHT H. POSITION H. SIZE V. POSITION
V. SIZE COLORTEMP VIDEO LEVEL DISP. FREQ UNGUAGE
AUTO SIZE RECALL OSD POSmON PICTURE
When the resolution is 1024 x 768
►3 nt IDI
5 e? :© EQ
If o m
a
?t
100
MENU CONTRAST
CONTRAST BACKLIGHT H. POSITION V. FINETUNE V. POSITION
H. FINETUNECOLOR TEMP VIDEO LEVEL DISP. FREQ LANGUAGE
AUTO SIZE RECALL OSD POSITION PICTURE
Adjustment Item Screen
d CONTRAST (White level)
Adjust the screen contrast. (Standard level = 100)
Press the MENU key to register the setting value.
Direct operation: Even if the menu screen does not appear, the contrast can be adjusted by
pressing the “+” or keys.
BRIGHTNESS (Black level)
Adjust the brightness (low gradation part: black level). (Standard level = 50)
Direct operation: Even if the menu screen does not appear, the contrast can be adjusted by
pressing the “0” or “[>” keys. Press the MENU key to register the setting value.
iCi-2 BACKLIGHT
Adjust the brightness of the backlight (Standard value = 100) by pressing the “+” or keys.
[Ql H. POSITION
The horizontal position of the image can be adjusted by pressing t h e o r keys.
O H. SIZE
‘Adjustment when the resolution is set from 640 x 400 to 832 x 624
The horizontal amplitude of the image can be adjusted.
After aligning the left edge of the image by the horizontal position adjustment, change to the
horizontal size adjustment and perform the adjustment by pressing the or keys.
V. FINETUNE
‘Adjustment when the resolution is 1024 x 768
When the 1024 x 768 screen resolution is used, vertical stripes may be observed depending
on the desktop patterns or applications. If this occurs, perform the following adjustments.
Display a screen which has vertical stripes and align the right side of the screen by the
horizontal position adjustment, then change to the vertical stripe adjustment (V. FINETUNE)
and perform the adjustment using the “+" or keys.
