On-Screen Display (OSD)
The meaning of the items displayed in the
on-screen display are described below.
O
<3
di cd- cd+
MENU
Adjusts the sound volume for the built-in
speakers and the headphone terminals.
<1
>
- and + keys
These keys set the level of the adjustment
items. Direct operation: These keys perform
the screen display contrast and other
adjustments.
MENU key
<1
and > keys
This key turns the menu screen on and off.
These keys select the adjustment items by shifting
Direct operation: These keys perform the screen
display brightness and other adjustments.
Direct Screen
There are three adjustments, contrast and brightness and mute and volume on the direct
screen.
Menu Screen (When the resolution is set
from 640 x 400
to
832 x 624)
The menu screen displays icons for the adjustment items of this unit.
However, brightness level 1 cannot be adjusted on the menu screen. (See Page 13
BRIGHTNESS (Black level).)
- 1 1 -
