Storing of Data
1. Factory Preset Timings
The display unit is shipped from the factory with the following eight timing modes.
Data
segment
Display
element
Horizontal
frequency
Vertical
frequency
Polarity of synchronizing
signal
Display area
TX-1703MA Series TX-2013MA Series TX-2103MA Series
H. Sync
V.Sync
H, size
V. size
H. size
V. size
H. size
V, size
1 VGA350 640 X 350 31.47kHz
60 Hz
+
-
298mm 224mm 350mm 262mm 376mm 282mm
2 VGA400 640 X 400 31.47kHz
60 Hz
-
3 VGA480 640 X 480 31,47kHz
60 Hz
-
-
4 MAC-II 640 X 480 35.0kHz 66.7 Hz
Sync on Green or
Composite Sync (-/-)
281mm 211mm 330mm 248mm 354mm 266mm
5 SUPER
VGA
800 X 600 35,16kHz 56.2 Hz
+
298mm 224mm 350mm 262mm 376mm . 282mm
6 8514/A 1024 X 768 35.52kHz86,95 Hz
(Interlace)
+
+
7 48.37kHz1024 X 768 48.37kHz 60.5 Hz
Sync on Green
8 63.7kHz1280 X1024 63,7kHz
60 Hz
Sync on Green
290mm 232mm 340mm 272mm 362mm 290mm
When the same signal as one of the above preset timings is input, the display area of the image is
displayed as indicated in the above table.
2. Custom Timings
o In addition, this unit is provided with 8 blank storage areas for saving timings different from those
listed above.
o
If any of the following four signals differ, the timing can be registered as different data.
1. Horizontal frequency
2. Vertical frequency
3. Polarity of horizontal synchronizing signal
4. Polarity of vertical synchronizing signal
o The contents of the data which can be registered by pressing the memory button is as follows:
1. Horizontal frequency
2. Vertical frequency
3. Polarity of horizontal synchronizing signal
4. Polarity of vertical synchronizing signal
5. Horizontal size
6. Horizontal position
7. Vertical size
8. Vertical position
- 7 -
