Monitor Care
o Before cleaning stains from the surface of the CRT, make sure to turn off the power, and use a
soft cloth to wipe away any stains. Because the surface of the CRT is easily scratched, avoid
rubbing the surface with anything other than a soft cloth.
o Stains from the cabinet should be wiped off using a cloth which has been soaked in a neutral de
tergent. Before wiping, the cioth shouid be squeezed to remove excess moisture.
Specifications
TX-1703MA Series
TX-2013MA Series
TX-2103MA Series
Power supply
Input voltage:
Frequency:
AC 90-264 V
50 / 60 Hz
Power consumption:
140 W max.
150 W max.
Input signal
Video signaling system:
Signal level:
Frequency:
Synchronized signaling
system:
Signal level:
RGB analog
0.714 Vp-p (no synchronizing signal)/1.0 Vp-p (with synchronizing signal)
(Based upon RS-343A)
100 MHz Typ.
Separate, composite and sync on green system
(automatic selection)
TTL level/0,286 Vp-p
Horizontal timing
Allovable Frequency range:
Blanking time:
Back porch time:
Front porch time:
Sync width time:
30.0-64.0 kHz
4.0 ps min.
1.25 ps min.
Length of back porch time or less
1.2ps min.
Vertical timing
AllowabieFrequency range:
Blanking time:
Back porch time;
Sync width time:
50.0-90.0 Hz
0,6 ms min.
0.5 ms min.
0.045 ms min.
Connector
Power supply:
signal:
CEE 22 type three pin connector
BNC connector X 5/15 pin mini D-sub connector (female pins)
(switch select)
CRT
Size:
17 inches
20 inches
21 inches
Dot pitch:
0.28 mm
0.31 mm
Phosphor:
Surface treatment:
RGB short persistence
silica coat ESF (Electro-Static Field) treatment
Service environment
Temperature:
Humidity:
0-40X
5-90%
Outside dimensions: (W-H-D) 413 X 434 X 480 (mm)
484 X 478 X 536 (mm)
510X 492X 567 (mm)
Weight:
24kg
26kg
32kg
All specifications are subject to change without notice.
