9. Specifications
ANALOG CIRCUITRY
Frequency Response
20 Hz —20 kHz.
Dynamic Range
Better than 85 dB, effect OFF.
Total Harmonic Distortion
Less than 0.1% @ 1 kHz, effect OFF.
Input Impedance/Nomlnal Level
Greater than 500 kohms/-20 dBm (Unbalanced phone
jack, front and rear).
Output Impedance/Nomlnal Level
1 k-ohm/-20 dBm or-10 dBm, switchable (Unbalanced
phone jacks x 2).
Headphone Impedance/Nomlnal Level
150 ohms/-22 dBm (Unbalanced stereo phone jack).
DIGITAL CIRCUITRY
AID and D/A Converters
16-bit quantization (linear).
Sampling Frequency
44.1 kHz
'
EFFECTS & MEMORY
Effect Stages
COMPRESSOR, DISTORTION, EQUALIZER,
MODULATION (Chorus, Flanger, Symphonic, Tremolo),
REVERB (Reverb, Early Reflection, Delay, Echo,
Reverb+Delay, Reverb -* * Delay, Delay Reverb)
Memory
ROM area: 60 (No. 1 — 60)
RAM area: 30 (No. 61 — 90)
Initial data area: 1 (No. 0)
FRONT PANEL
Control & Keys
INPUT LEVEL control, COMP, DIST, EQ, MOD, REV,
A,
▼, SEL/ASN, BYPASS, STORE, MEMORY (◄),
RECALL, PARAM ( ►), UTILITY, POWER
Connector
INPUT jack.
Display
Backlit LCD with 7-segment program number, BYPASS,
and 15-character x 2-line display area.
LED
PEAK, SIGNAL
Switch
POWER (on/off)
•
REAR PANEL
Connectors
INPUT, OUTPUT L, OUTPUT R, PHONES, BYPASS,
MEMORY INC/DEC or TRIGGER, MIDI IN, DC 12V IN
Control
PHONES LEVEL
Switch
OUTPUT LEVEL -20dB/-10dB
GENERAL
Power Supply
U.S. & Canadian Models: PA-1207U AC Adaptor
(120 VAC)
General Model: PA-121 OH AC Adaptor (220/240 V AC)
Dimensions (W x H x D)
220 X 45 X 250 mm (8-5/8" x 1-3/4" x 9-7/8")
Weight
1.4 kg (3 lbs. approx.)
• 0dB = 0.775 Vrms
• Specifications and exterance are subject to change without
nofice.
