! T Y P L - D L Ï R - D L Ï
R + D 1 9 0 . 0 3 8 0 . 0
' T Y P F B L / R R V T
R + D 4 3 L = R 2 . 4
; T Y P R / D « I X L V L
R + D
5 0 0 0
L-DLY (Left Channel Delay Time: 0.1 — 380.0 ms)
Sets the delay time of the left channel.
R-DLY (Right Channel Delay Time: 0.1 — 380.0 ms)
Sets the delay time of the right channel.
FB (Feedback: 0 —100 %)
Determines the amount of effect-sound feedback returned
to the input of the processor. Higher values produce a a
greater number of repeats.
UR (L/R Channel Delay Level Balance: 0 — 100 %)
Sets the left-to-right channel balance of the delay sound
level. Higher values produce higher-level delay sound from
the left channel, and smaller values produce a high-level
delay sound from the right channel.
RVT (Reverb Time: 0.3 — 40 s)
Sets the duration of the reverb effect.
R/D (Reverb/Delay Level Balance: 0 —100 %)
Determines the balance between the level of the reverb
and delay sound. Higher values produce a greater
proportion of reverb sound, while smaller values produce a
greater proportion of delay sound.
MIX (Mixing Balance: 0 —100 %)
Sets the balance between the direct and effect sound.
Higher values produce a greater proportion of effect sound
in relation to direct sound.
LVL (Output Level: -41 — dB)
Determines the output level of the effect.
• Reverb and Delay Group (Serial)
■ Delay -♦ Reverb (D -♦ R)
' Reverb -♦ Delay (R -» D)
IN' DELAY REVERB
►our
The Delay -» Reverb program provides both delay and
reverb, with delay before reverb.
The Reverb -»Delay provides delay and reverb with
reverb before delay.
IN ■ REVERB DELAY ►OLIT
' T Y P L - D L Y R - D L Y
R.>D 2 9 0 . 0 3 2 0 . 0
' T Y P F B L / R D H X
R - > D 2 8 L = R 0
' T Y P R V T R M X L V L
R + D 2 . 6 0 0
L-DLY (Left Channel Delay Time: 0.1 — 380.0 ms)
Sets the delay time of the left channel.
R-DLY (Right Channel Delay Time: 0.1 — 380.0 ms)
Sets the delay time of the right channel.
FB (Feedback: 0 — 100 %)
Determines the amount of effect-sound feedback returned
to the input of the processor. Higher values produce a a
greater number of repeats.
UR (UR Channel Delay Level Balance: 0 —100 %)
Sets the left-to-right channel balance of the delay sound
level. Higher values produce higher-level delay sound from
the left channel, and smaller values produce a higher-level
delay sound from the right channel.
DMX (Delay Mixing Balance: 0 —100 %)
Sets the balance between the direct and delay sound.
Higher values produce a greater proportion of delay sound
in relation to direct sound.
RVT (Reverb Time: 0.3 — 40 s)
Sets the duration of the reverb effect.
RMX (Reverb Mixing Balance: 0 — 100 %)
Sets the balance between the direct and reverb sound.
Higher values produce a greater proportion of reverb
sound in relation to direct sound.
LVL (Output Level: -41 — +6 dB)
Determines the output level of the effect.
■
18
