Sets the balance between the direct and effect sound.
Higher values produce a greater proportion of effect sound
in relation to direct sound.
LVL (Output Level: -41 — -^6 dB)
Determines the output level of the effect.
MIX (Mixing Balance: 0 —100 %)
Although similar to the Delay program, the Echo program
has different delay ranges and different "internal" settings
that result in a distinctive echo effect.
• Echo (Ech)
; t y p l - d l y r - d l y
E c h 3 6 6 . 0 3 7 0 . 0
; t y p f b l / r
E c h 20 R l l
• Delay Group
• Delay (Dly)
This sophisticated delay effect offers independently
variable left and right channel delays (repeats).
/ T Y P H I X L V L
E c h 0 0
; t y p l - d l y r - d l y
D l i 3 6 6 . 2 5 0 8 . 0
; t y p f b l / r
D l y 4 0 L = R
1 T Y P H I X L V L
D l y 1 5 + 4
L-DLY (Left Channel Delay Time: 0.1 — 740,0 ms)
Sets the delay time of the left channel.
R-DLY (Right Channel Delay Time: 0.1 — 740.0 ms)
Sets the delay time of the right channel.
FB (Feedback: 0 —■ 100 %)
Determines the amount of effect-sound feedback returned
to the input of the processor. Higher values produce a a
greater number of repeats.
L/R (L/R Channel Delay Level Balance: 0 —100 %)
Sets the left-to-right channel balance of the delay sound
level. Higher values produce higher-level delay sound from
the left channel, and smaller values produce a higher-level
delay sound from the right channel.
MIX (Mixing Balance: 0 —100 %)
Sets the balance between the direct and effect sound.
Higher values produce a greater proportion of effect sound
in relation to direct sound.
LVL (Output Level: -41 —
-tS
dB)
L-DLY (Left Channel Delay Time: 0.1 — 370.0 ms)
Sets the delay time of the left channel.
R-DLY (Right Channel Delay Time: 0.1 — 370.0 ms)
Sets the delay time of the right channel.
FB (Feedback: 0 — 100 %)
Determines the amount of effect-sound feedback returned
to the input of the processor. Higher values produce a a
greater number of repeats.
L/R (L/R Channel Delay Level Balance: 0 —100 %)
Sets the left-to-right channel balance of the echo sound
level. Higher values produce higher-level echo sound from
the left channel, and smaller values produce a higher-level
echo sound frorn the right channel.
MIX (Mixing Balance: 0 —100 %)
Sets the balance between the direct and effect sound.
Higher values produce a greater proportion of effect sound
In relation to direct sound.
LVL (Output Level: -41 — +6 dB)
Determines the output level of the effect.
• Reverb and Delay Group (Parallel)
• Reverb + Delay (R- f D)
This effect functions like separate reverb and delay
processors connected in parallel.
Determines the output level of the effect.
REVEFB
IN —
DELAY
►cxrr
17
