Before Using (continued)
Reset all unit Memory
Functions
Use when moving unit to a new location, or if a mistake
was made in the One Time Setup section.
• Make sure a tape is not inserted in the unit.
Head Cleaning
the unit for more than 5 seconds.
• The power will shut off.
3
Do “One Time Setup” Steps on page 12.
DST. (Daylight Saving Time)
Unit auto adjusts clock for DST (Daylight Saving Time).
Spring (First Sunday in Aprii)
DST:ON ^ Sets clock ahead one hour.
1:00 a.m. 2:00 a.m.
NORMAL TIME
DAYLIGHT
SAVING TIME
3:00 a.m. 4:00 a.m.
Autumn (Last Sunday in October)
DSTON -♦ Turns clock back one hour.
DAYLIGHT
SAVING TIME
1:00 a.m. 2:00 a.m.
NORMAL TIME
1:00 a.m. 2:00 a.m.
• If your area does not observe Daylight Saving Time,
select DSTOFF (See page 13.)
• Keep these time changes in mind when programming
the unit for timer recordings.
Playing older or damaged tapes may eventually cause video
heads to become clogged.
Head Ciog Sensor
During playback this screen appears if clogging is
detected. To remove screen, press PLAY on the
remote or unit.
• Use “dry” type head
cleaning cassette only.
(Part No. NV-TCL30PT
is recommended.)
• Follow cleaning tape
carefully. Excessive use of
tape can shorten head life.
• If head clog symptoms
persist, contact your nearest Factory Service Center or
authorized Service Center. (See Back Cover.)
VIDEO HEADS MAY NEED CLEANING
P
lease I NSHRT HEAD
CLEANING CASSETTE
on REFER TO MANUAL
Specifications
Display
Picture Tube:
VCR
Video Recording System:
Audio Track:
Tuner
Broadcast Channels:
CABLE Channels:
FM Radio
Band range:
General
Power Source:
Power Consumption:
Television System:
Speaker:
Operating Temperature:
Operating Humidity:
Weight:
Dimensions:
Discs played
(1) DVD-VIDEO disc
(2) Compact disc
(CD-DA, VIDEO CD)
Digital audio output:
Optical digital output:
Coaxial digital output:
Pickup:
27 inch measured diagonal
100“ deflection Picture Tube
4 rotary heads helical scanning system
1 track (Normal)
2 channel (Hi-Fi Audio Sound)
VHF2-13, UHF 14-69
Midband A through I (14-22)
Superband J through W (23-36)
Hyperband AA-EEE (37-64)
Lowband A-5-A-1 (95-99)
Special CABLE channel 5A (01)
Ultraband 65-94, 100-125
87.5-108.1 MHz
120V AC, 60 Hz
Approx. 170 watts (Power on)
Approx. 5.5 watts (Power off)
EIA Standard NTSC color
2 pieces
5“C-35“C (41“F~95°F)
10%~75%
40.5 kg (89.1 lbs.)
688 (W) x 653 (H)
X 550 (D) mm
27-1/16" (W) X 25-11/16" (H)
X 21-5/8” (D)
5“ (12 cm) singie-sided, single-layer
5“ (12 cm) single-sided, double-layer
5" (12 cm) double-sided, double-layer
(one layer per side)
S" (8 cm) single-sided, single-layer
3" (8 cm) single-sided, double-layer
3“ (8 cm) double-sided, double-layer
(one layer per side)
5" (12 cm) disc 3" (8 cm) disc
Optical connector
Pin jack
Wave length: 655nm
Laser power: CLASS II
Note: Designs and specifications are subject to change
without notice.
