Convergence Adjustment
Convergence Adjustment for GREEN, RED and BLUE
Use the Position Up V’ or Down “v” button to
align the horizontal green line with the vertical
centre marker.
<10^ CONVERGENCE
GREEN
N0(T:[Nj
© Vertical center
marker
Use the Position Left “<” or Right “>” button to
align the vertical green line with the horizontal
centre marker.
d] CONVERGENCE
<|^E> GREEN
NEXTriN]
o
Morizontal centre marker
Push the “N” button to adjust the red mode.
(Stores green)
\7
i
CONVERGENCE
<=i
red
NEXT:®
Use the Position Up “ a ” or Down "v” , Left “<” or
Right “>” buttons to align the red line with the
green line, (Becomes a yellow line)
4 cs ^
Push the “N" button to adjust the blue mode.
(Stores red)
¿2^
<\m\)
Use the Position Up “ a ” or Down V’, Left “<” or
Right “>” buttons to align the blue line with the
yellow line. (Becomes a white line)
^ CEl ^
Push the “N" button to return to the normal
viewing. (Stores blue)
22
<1 ® [>
If you wish to view a video with a different colour
system (PAL / SECAM, NTSC), repeat the steps
above while displaying a picture.
