User Mode
Item User mode Item User mode
Picture Level ±0 Chroma Detail 0
Light PEAK/AVG 0 Flesh Noise Suppress OFF
Light Area Top cut
Detail Set 2Corner Detail
OFF
Auto Iris Adjust OFF Precision Detail OFF
Iris, Shutter, Shutter Mode Step
Gain Set Step OFF Matrix{R-G) -18
Synchro Scan Matrix(R-B) -19
Field/Frame Field Color Matrix(G-R) -10
Gain OdB Matrix Set Matrix(G-B)
Pedestal ±0 Matrix(B-R) +10
+ 10
Chroma Level ±0
White Bal AWC A Gamma 0.45
High-light Chroma OFF Knee Point 97%
Painting R Gain ±0 White Clip 103%
B Gain ±0 Flare R 0
R Pedestal ±0 Flare G 0
B Pedestal ±0
Other Setl Flare B
0
2D LPF OFF Black Stretch OFF
Baud Rate 9 600bps
H Phase ±0
Nega/Posi Posi
G/L, Color SC Coarse 1
Aspect Ratio 16 : 9
Bar Set SC Fine ±0
Color Bar Set 7.5 IRE
Fan ON
Detail HIGH
H Detail Level H +11
Other Set2
V Detail Level H +12
H Detail Level L +7
Detail Set 1V Detail Level L +6
Detail Band 2
Noise Suppress 3
Level Dependent 0%
Dark Detail 0
-
