CONNECTIONS

Caution:

The connection and installation should be done by qualified service personnel or system installers.

Refer any servicing to qualified service personnel.

■ CONNECTION OF DEVICE WITH A COMPOSITE INPUT CONNECTOR

• Connection to any device which has a composite input connector, such as a video monitor or a VTR, must be made

through the VIDEO OUT Connector.

• Power supply to the camera must be through the optional DC power supply Cable AW-CA4T1.
• For DC power supply, use the optional AC adaptor AW-PS505.
