FLANGE BACK ADJUSTMENT (FOR ZOOM LENS)
1. Fully open the iris by shooting a dark object. (Iris
selection switch should be set to M.)
2. Loosen the flange back lock knob.
3. Aim the camera at any object over 2 meters away
from the camera.
4. Set the lens to its TELE end first and adjust its focus
with the focus ring,
5. Set the lens to its widest angle next and adjust its
focus with the flange back adjust ring.
6. Adjust the focus ring and the flange back adjust
ring alternately for the best focus within the zoom­
ing range,
Tighten the flange back lock knob upon completion
of focusing.
7. Turn the iris selection switch to Position A.
