Sub Carrier Phase Coarse Adjustment

[SC Coarse: 1/2/3/4]

Coarse adjustment of subcarrier phase can be
made when a genlock signal is supplied.

Щ) Subcarrier Phase Fine Adjustment [SC Fine:

-511 -+511]

Fine adjustment of subcarrier phase can be made

when a genlock signal is supplied,

Color Bar Setup Setting [Color Bar Set:

0.0 IRE/7.5 IRE]

The setup level of color bar can be adjusted.

Ф Detail Select Setting [DTL Select: Normal/Super

DTL]

If contour correction is not sufficient at the Normal
position when Detail Level setting ф is set to LOW

or HIGH, select the Super DTL position.

Ф Detail Level Setting [Level: OFF/LOW/HIGH]

Detail level can be adjusted when Detail Select set

ting Ф is at Normal. Super DTL level can be adjust
ed when it is at Super DTL.

In case of using the RCU (RGB), the above can be

adjusted with the contour correction switch (DTL).

RCU (RGB)

гл5^

rcbon

Q..

AIN—j

AGC

;

OfdB^ ^(dBt CAM

AWC

HOLD

TOTAL

RED >

Oí

Sh«UTTbM tiCtiNE

USifi' ^

I—

DTL Switch

Note

Neither Normal nor Super DTL is valid for contour

position.

® Noise Suppress Level Setting [Noise Suppress:

OFF/LOW/HIGH]

Screen noise can be reduced when Detail Level
setting is at HIGH or LOW.
