MENU ITEM SEHING

MENU ITEM SETTING

Each of the four use modes of the camera has a

main menu, (Shown at right)

Each item of the main menu has a submenu, which

consists of several settings.
These settings have been preset to the optimum
values to suit each use mode, and can be changed
to suit actual shooting conditions.
They can be set from the camera and RCU (RGB),
They can also be set from the hybrid control panel

using the switches, but the setting items are limited
because the menu is not shown.

Notes:

• Composite signals are output from the video

output regardless of the position ENC/VF of the

RCU (RGB) user set switch.

• [End] is displayed only in setting from the cam

era alone,

• [Option Card Set] is shown only when an

optional card is inserted.

MAIN MENU SCREEN

Main Menu of Halogen,

Fluorescent, Outdoor Mode

**Halogan Mode Set**

Brightnees Set
Color Set
0/L, Color Bar Set
Sharpness(DTL) Set
Other Set
Option Card Set

Initialize Data

End

Use Mode

Blinking

Main Menu of User Mode

**Usor Mode Sot**

Iris, Shutter, Gain Set

Color Set
0/L, Color Bar Set
Detail Setl Detail Set2
Color Matrix Set
Other Setl Other Set2
Option Card Set

Initialize Data

End
