Reset all Combination VCR
Memory Functions
Use when moving Combination VCR to new location,
or if a mistake was made in the One Time Setup
section.
• Make sure a tape is not inserted in the Combination VCR.
VCR Power on. the PLAY and FF on
the Combination VCR
for more than 5
seconds.
• The power will shut off.
Do One Time Setup Steps on page 8.
Head Cleaning
Playing older or damaged tapes may eventually
cause video heads to become clogged.
Head Clog Sensor
During playback this screen appears if clogging is
detected. To remove screen, press PLAY on the
remote or Combination VCR,
• Use “dry” type head cleaning
cassette only. (Part No. NV-
TCL30PT is recommended.)
• Follow cleaning tape carefully.
Excessive use of tape can
shorten head life.
• If head clog symptoms persist,
contact your nearest Factory Service Center or
authorized Service Center. (See page 41.)
VIDEO HEADS MAY
NEED CLEANING
PLEASE iNSERT HEAD
CLEANING CASSETTE
OH REFER TO MANUAL
END:PLAY KEY
Record/Playback Time
Only use tapes with the IVHSI mark in this unit.
Tape Speed
Setting
Type of Video Cassette
T60 T120 T160
SP
(Standard Play)
1 Hour 2 Hours
2 Hours
40 minutes
LP
(Long Play)
2 Hours 4 Hours
5 Hours
20 minutes
SLP
(Super Long Play)
3 Hours 6 Hours 8 Hours
DST (Daylight Saving Time)
Combination VCF
(Daylight Saving'
Spring (First S i
DST:ON Sets c
t auto adjusts clock for DST
rime.)
unday in April)
:lock ahead one hour.
1 NORMAL TIME
1 1:00 a.m, 2:00 a.m.
DAYLIGHT
SAVING TIME
3:6b a.m. 4:00 a.m.
Autumn (Last Sunday in October)
DST:ON Turns clock back one hour.
DAYLIGHT
SAVING TIME
1:00 a.m. 2:00 a.m.
NORMAL TIME
i------------ -
- - - - - - - - - - - - ^
• If your area does r
select DST: OFF.
• Keep these time cl
the Combination V
1:00 a.m. 2:00 a.m.
lot observe Daylight Saving Time,
hanges in mind when programming
^CR for timer recordings.
Specifications
Display
Picture Tube:
VCR
Video Recording System:
Audio Track:
Tuner:
Broadcast Channels:
CABLE Channels:
FM Radio
Band range:
General
Power Source:
Power Consumption:
Television System:
Speaker:
Operating Temperature:
Operating Humidity:
Weight:
Dimensions:
9 inch measured diagonal 90“
deflection Picture Tube
2 rotary heads helical scanning
system
1 track
VHF2~13, UHF 14-69
Midband A through I (14-22)
Superband J through W (23-36)
Hyperband AA-EEE (37-64)
Lowband A-5-A-1 (95-99)
Special CABLE channel 5A (01)
Ultraband 65-94,100-125
87.5-108.1 MHz
120V AC, 60 Hz (AC)
12V/24V (DC)
Power on
Approx. 64 watts (AC)
Approx. 59 watts (DC)
Power off
Approx. 3.5 watts (AC)
Approx. 0.8 watts (DC 12V)
Approx. 1.5 watts (DC 24V)
EtA Standard NTSC color
1 piece
41“F-104“F(5“C-40"C)
10%-75%
20.1 lbs. (9.1 Kg)
11-7/8" (W)X 12-7/8" (H)X
13-3/16" (D)
302 (W) X 327 (H) X 335 (D)
mm
Note: Designs and specifications are subject to change
without notice.
