ASPECT RATIO FORMATS
Source
Signal
16:9 MONITOR FORMAT
FULL
ZOOM
SIDEBAR
EXPAND
4:3 MONITOR FORMAT
FULL
ZOOM LETTERBOX SHRINK
16
H H n
B D O @
The 16:9 and 4:3 pictures
represent the incoming
source signals received
by the STB.
These pictures show the different aspect ratios
available with a 16:9 monitor format.
•
The top picture shows the 16:9 monitor
format available when the STB receives a
16:9 source signal.
•
The bottom pictures show the 16:9 monitor
formats available when the STB receives a
4:3 source signal.
These pictures show the different aspect ratios
available with a 4:3 monitor format.
•
The lop pictures show the 4:3 monitor
formats available when the STB receives a
16:9 source signal.
•
The bottom picture shows the 4:3 monitor
format available when the STB receives a
4:3 source signal.
