EdgeAccess Universal Chassis System
Table 4. SNMP Configuration Parameters Description
Item Description
1) System Contact
2) System Name
3) System Location Local information for the 6703, up to 50 characters in each field
4) Read Community Name for the people who can view the reports, up to 10
characters; default is
public
5) Write Community Name for the people who can set values for parameters, up to 10
characters; default is
public
6) SLIP/PPP IP Address Enter the IP address for access through SLIP or PPP
7) Ethernet IP Address Enter the IP address for access through the Ethernet network
8) Ethernet Subnet Mask Enter the mask that sets the network ID part of the IP address
9) Ethernet Default Gateway Enter the address of the network node that connects to another
network
10) BOOTP Enabled Enable this if the module needs to obtain its IP address from a
BOOTP server; when the unit has an IP address, disable BOOTP
11) Serial Port Config Set the type of serial port connection: VT100 (default), SLIP, or
PPP
12) Telnet Timeout Set the time with no activity until a Telnet connection
automatically logs out
13) Host Table Access the Host Table screen
3.4.5 Host Table
The SNMP agent allows access to up to 24 Host IP addresses listed in the Host Table. Set up the
Host information for the 6703 on the Host Table screen. See Figure 11. To access the Host Table,
follow these steps:
1. From the SNMP Configuration menu, type 13 , "Host Table," and press . The Host Table
screen appears.
2. To add a host, type 1 and press , then follow the prompts, to enter values for these
parameters:
a. IP Address for the Host
b. Access level for the host; can be 1 , read; 2 , read/write; 3 , read/trap; or 4 , read/write/trap
c. Trap community string (up to 10 characters)
3. To delete a host, type 2 and press , press to highlight the host address, and press
. The host table appears again with your changes.
4. To return to the SNMP Configuration menu, press .
CWDM Transponder Model 6703 3-8
