EdgeAccess Universal Chassis System
---------------------LAYER 2 STATISTICS (CURRENT)---------------------
Local Local Remote 9145 Remote 9145
User Port Ext Port Ext Port User Port
Link State ** DOWN ** UP UP ** DOWN **
Speed/Duplex N/A 100M/FULL 100M/FULL N/A
Frames Sent 0 0 183920 0
Frames Rcvd 0 183921 0 0
Bytes Sent 0 0 11770880 0
Bytes Rcvd 0 11770944 0 0
Undersize < 64 0 0 0 0
Oversize > 10000 0 0 0 0
Frames > 1518 0 0 0 0
Frames Sent Rate 0/s 0/s
Frames Rcvd Rate 0/s 1/s
Last Counter Reset: 2 days 03:05:41
Select [(N) Remote RMON Statistics, (M) More Remote Statistics,
(E) Error Counters, (CTRL-T) Raw Counters, (CTRL-R) Reset Counters]:
-------------------Hit 'ESC' to return to previous menu---------------
Figure 4-31. Layer 2 Statistics Screen
4.10 Utilities
Use the Utilities screen to set the time and date, update modem, SLIP, or PPP parameters, or to run
the diagnostic PING. See Figure 4-32 and Table 4-12. Options 5 through 9 are available only when
the L351 is in a standalone enclosure. To access the Utilities screen, follow these steps:
1. From the Main Menu, type 6 , Utilities, and press . The Utilities menu appears.
2. To return to the Main Menu, press .
----------------------------------UTILITIES---------------------------
1) Set Date and Time
2) Reset Configuration To Default
3) Reset Remote Configuration To Default
4) Remote Craft Port: Enabled
5) Modem/Slip/PPP Baud Rate 19200
6) Modem Initialization String AT
7) PING Generation
8) Static ARP Table
9) Dynamic ARP Table
Select [1-9]:
-------------------------------Messages-------------------------------
Figure 4-32. Utilities Menu Screen
L351 10/100BASE Media Converter 4-35
