EdgeAccess Universal Chassis System
4.5.6 IP/SNMP Agent Configuration
If the L351 is in a Model 1020, use the IP/SNMP Agent Configuration screen to view and set up the
SNMP parameters. To view SNMP parameters, follow these steps:
1. At the System Configuration menu type 6, IP/SNMP Agent Configuration, and press
. The IP/SNMP Agent Configuration screen appears (see Figure 4-17 and Table 4-4).
---------------------IP/SNMP AGENT CONFIGURATION--------------------
1) Management IP Configuration
2) Host Table
3) Trap Table
4) Remote Auxiliary IP Configuration
Select [1-4]:
------------------------------Messages------------------------------
Figure 4-17. IP/SNMP Agent Configuration Screen
Table 4-4. SNMP Configuration Parameters Description
Item Description
1) Management IP
Configuration Access the IP Configuration Management Screen
2) Host Table Access the Host Table screen (for standalone enclosure, only)
3) Trap Table Access the Trap Table screen (for standalone enclosure, only)
4) Remote Auxiliary IP
Configuration Access the Remote Auxiliary IP Configuration Management Screen
2. Type 1 to access the IP Configuration Management screen, which will allow you to modify
the configuration settings shown in Figure 4-17 and described in Table 4-5.
--------------------------MANAGEMENT IP CONFIGURATION-----------------
Local Remote 9145
MAC Address 00 40 2A 00 58 2D 00 40 2A 00 B3
E2
Management Port DOWN UP
1) Manager IP Address 172.016.085.055
172.016.085.075
Subnet Mask 255.255.000.000
255.255.000.000
Default Gateway 172.016.001.001
172.016.001.001
2) SLIP/PPP IP Address 000.000.000.000
000.000.000.000
3) Serial Port Config VT100 VT100
4) BOOTP Disabled
5) Telnet Security Disabled Disabled
6) Test IP Address
172.016.085.013
Figure 4-18. ManagementIP Configuration Screen .
L351 10/100BASE Media Converter 4-19
