EdgeAccess Universal Chassis System
4.8 System Alarms
Use the System Alarms screen to view alarms and faults on the L351. See Figure 4-30. To view
alarm status:
1. From the Main Menu, type 4, System Alarms, and press . The System Alarms screen
appears.
2. When you finish checking the Alarm status, press to return to the Main Menu.
--------------------------------SYSTEM ALARMS-------------------------
Local Remote 9145
Configuration Errors No No
User Port *** Down *** *** Down ***
Extension Port Up Up
User Port Remote Fault N/A N/A
Ext Port Remote Fault No No
Link Loss Echo No
Link Loss Fwd Ext->User No No
Link Loss Fwd User->Ext No No
Side Band Mgmt Channel OK OK
User SFP Transmitter N/A N/A
Extension SFP Transmitter N/A N/A
Chassis Management N/A
Alarm Relay Inputs N/A
Power Supply Primary OK OK
Power Supply Secondary N/A
Fan N/A
Chassis Temperature N/A
-------------------Hit 'ESC' to return to previous menu---------------
Figure 4-30. System Alarms Screen
4.9 Layer 2 Statistics
Use the Layer 2 Statistics screen to view data transfer protocol statistics on the L351. See Figure
4-31. To view layer 2 statistics, follow these steps:
1. From the Main Menu, type 5, Layer 2 Statistics, and press . The Layer 2 Statistics
screen appears.
2. To reset the counters, press .
3. To view additional statisctics for the remote module, press . At that screen, you can
access remote RMON statistics; tyep 2 and press .
4. When you finish checking the statistics, press to return to the Main Menu.
4-34 L351 10/100BASE Media Converter
