EdgeAccess Universal Chassis System
Create and Manage Virtual Groups
You can set up a Virtual Group to upgrade software or swap memory banks on two or more
modules of the same type at the same time; the DMM can support up to 32 Virtual Groups. You
can create, edit, and delete Virtual Groups within the Domain. To access the Virtual Group menu
and manage the groups, follow these steps:
1. At the Main Menu, type 2 , "Manage or access a specific Virtual Group" and press .
The Virtual Group Management screen appears. See Table 9.
Table 9. Virtual Group Menu Options
Menu Option Description
1. Select Virtual Group Choose an existing Virtual Group; opens the Virtual Group Management
menu
2. Create Virtual Group Opens the Virtual Group Management menu
3. Delete Virtual Group Remove an existing Virtual Group
2. To create a Virtual Group, at the Virtual Group Management menu, type 2 , "Create Virtual
Group."
3. At the prompt, enter the name, up to 15 characters, and press . The Virtual Group
Management screen appears; it identifies the module type and Chassis and slot numbers for
each item in the group. See Figure 6.
VIRTUAL GROUP MANAGEMENT
Virtual Group Name: 2345
Item Chassis Slot Module-Model
1 1 2 2345-Modem
2 1 3 2345-Modem
3 1 4 2345-Modem
Figure 6. Typical Virtual Group Management Screen
4. At the Virtual Group Management screen, make any of these selections:
• To add a module to a Virtual Group, type
1 , then at the prompt, enter the Chassis and
Slot for the module, and press .
• To delete a module from the selected Virtual Group, type
2 , then at the prompt, enter the
Chassis and Slot for the module, and press .
Note: The delete option in the Virtual Group Management menu deletes an entire Virtual
Group. To delete a single module in a Virtual Group, first select the Virtual Group, then
at the Virtual Group Management screen, select and delete that module.
• To reset all modules in the selected Virtual Group, type
r and press .
• To swap firmware banks in all modules in the selected Virtual Group, type
s and press
.
5. To return to the Main Menu, press ; any changes to groups are saved automatically.
3-22 Model 1502 Domain Management Module
