EdgeAccess Universal Chassis System
Manage the DMM
The DMM provides communication with and some controls of the various chassis and modules
within the domain. Most configuration options for basic information and communications
parameters are available from the Domain Management Module menu. To reach the Domain
Management Module screen, follow these steps:
1. At the Main Menu, type 1 , "Manage or access the Domain Management Module," and press
. The Domain Management Module menu appears; see Table 3.
2. To return to the Main Menu, press .
Table 3. Domain Management Module Menu Selections
Menu Item Description
1. System Configuration Set values for the system information and communications
parameters
2. Change Security & Passwords Set up system security and access
3. Ping Generation Send a PING from the DMM to a specific IP address
4. Software Upgrade Download and install new firmware
5. Trap Configuration Set the DMM conditions that generate SNMP traps
6. Host Table Set up managing hosts for accessing the DMM and
receiving traps
7. Trap Destination Table Set up notification by destination
8. Modem/SLIP/PPP Configuration Set up the serial communication port
9. Set Date and Time Set date and time for the DMM; this information is passed
to each module in the domain
10. SNTP Configuration Set up SNTP parameters.
11. Syslog Configuration Set up parameters to send data to the Syslog server
Configure the DMM for the System
To set values for basic system parameters, including some SNMP parameters, as well as view
basic system information, go to the System Configuration report and menu. See Tables 4 and 5.
To access the System Configuration screen, follow these steps:
1. At the Domain Management Module menu, type 1 , "System Configuration," and press
. The System Configuration screen appears.
2. At the prompt, type an item number and follow the prompts on the screen. Table 5 lists
options for each menu item.
3. To return to the Domain Management Module menu, press .
Model 1502 Domain Management Module 3-5
