WEBS-ZPM-9 Zone Paging Module Instructions
Copyright 2009 Talk-A-Phone Co. All rights reserved.
Talk-A-Phone
Co.
• 7530 North Natchez Avenue • Niles, Illinois 60714-3804
Page 2 of 2
Phone 773.539.1100 • Fax 773.539.1241 • [email protected] • www.talkaphone.com
All prices and specifications are subject to change without notice.
Talk-A-Phone, Talk-A-Lert, Scream Alert and WEBS are registered trademarks of Talk-A-Phone Co
IV.
Setting the System ID
Once the WEBS-ZPS-9 Zone Paging Modules have been wired together, the System ID numbers can be
assigned. The ID for the master system (WEBS-ZPS) must be set to zero (all SYS ID switches set to “0”). The
table below shows the SYS ID switch settings for the available System ID numbers for the Zone Paging Modules
and the zones that each WEBS-ZPM-9 Zone Paging Module handles.
Zone Numbers
DIP Switch Settings for SYS ID
S1
S2
S3
S4
Master System
(WEBS-ZPS)
1
–
9
0 0 0 0
ZPM #1
10 – 18
|
0
0
0
ZPM #2
19 – 27
0
|
0
0
ZPM #3
28
–
36
| | 0 0
ZPM #4
37
–
45
0 0 | 0
ZPM #5
46 – 54
|
0
|
0
ZPM #6
55 – 63
0
|
|
0
ZPM #7
64
–
72
| | | 0
ZPM #8
73
–
81
0 0 0 |
ZPM #9
82 – 90
|
0
0
|
ZPM #10
91 – 99
0
|
0
|
| = On
0 = Off
