RECOMMENDED MOUNTING OF ETP-400
IN AN ETP-SM FOR ADA COMPLIANCE
Talk-A-Phone Co.
7530 North Natchez Avenue, Niles, Illinois 60714-3804
Phone: (773) 539-1100 Fax: (773) 539-1241
e-mail: [email protected] http://www.talkaphone.com
Page 2 of 2
All Specifications and Prices Subject to Change
WALL
FINISHED FLOOR
CEILING
TOP OF ETP-SM
CENTER OF REAR CONDUIT HOLE
BOTTOM CONDUIT HOLE
ETP-EL
ETP-MBKT
35"
41.5"
48"
CONDUIT FOR
COMMUNICATION LINE
OR
CONDUIT FOR
AUXILIARY LEADS
FROM ETP-400 TO ETP-EL
CONDUIT FOR POWER
TO BLUE LIGHT/STROBE
AS HIGH AS POSSIBLE, WITH MAXIMUM VISIBILITY
