7
MZ-2000 MIDI Implementation
Receive
n : Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv : Hold 1 = 00H to 7FH
The Hold 1 message is not received when Rx.Hold1 = OFF.
Send
n : Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv : Hold 1 = 00H, 7fH (00H:OFF, 7fH:ON)
The Hold 1 message is sent whenever the MZ-2000 sustain pedal is operated while the sustain
effect is assigned to the pedal, or when the sustain switch of the MZ-2000 is operated.
2.3.10 Portamento
Format
Byte 1 Byte 2 Byte 3
BnH 41H vvH
Receive
n : Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv : Portamento = 00H to 7FH (00H to 3fH:OFF, 40H to 7FH:ON)
The Portamento message is not received when Rx.Portamento = OFF.
Send
n : Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv : Portamento = 00H, 7fH (00H:OFF, 7fH:ON)
The Portamento message is sent whenever the assignable button of the MZ-2000 is operated when
the portamento effect is assigned to the button.
2.3.11 Sostenuto
Format
Byte 1 Byte 2 Byte 3
BnH 42H vvH
Receive
n : Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv : Sostenuto = 00H to 7FH (00H to 3fH:OFF, 40H to 7FH:ON)
Sostenuto is not received when Rx.Sostenuto = OFF.
Send
n : Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv : Sostenuto = 00H,7fH(00H:OFF,7fH:ON)
The Sostenuto message is sent whenever the MZ-2000 sustain pedal is operated when the sostenuto
effect is assigned to the pedal.
2.3.12 Soft
Format
Byte 1 Byte 2 Byte 3
BnH 43H vvH
Receive
n : Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv : Soft = 00H to 7FH (00H to 3fH:OFF, 40H to 7FH:ON)
The Soft message is not received when Rx.Soft = OFF.
Send
n : Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv : Soft = 00H, 7fH(00H:OFF, 7fH:ON)
The Soft message is sent whenever the MZ-2000 sustain pedal is operated when the soft effect is
assigned to the pedal.
2.3.13 Sound Controller 2 (Resonance)
Format
Byte 1 Byte 2 Byte 3
BnH 47H vvH
n : Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv : TVF Resonance = 00H to 7FH
Receive
This message is received when Rx.Control Change = ON and its channel matches the part MIDI
channel.
Send
The Sound Controller 2 message cannot be sent.
2.3.14 Sound Controller 3 (Release Time)
Format
Byte 1 Byte 2 Byte 3
BnH 48H vvH
n : Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv : TVA Release Time = 00H to 7FH
Receive
This message is received when Rx.Control Change = ON and its channel matches the part MIDI
channel.
Send
The Sound Controller 3 message cannot be sent.
2.3.15 Sound Controller 4 (Attack Time)
Format
Byte 1 Byte 2 Byte 3
BnH 49H vvH
n : Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv : TVA Attack Time = 00H to 7FH
Receive
This message is received when Rx.Control Change = ON and its channel matches the part MIDI
channel.
Send
The Sound Controller 4 message cannot be sent.
