MZ-2000 MIDI Implementation
8.
Delay Time R
Right-channel delay time
9.
Delay Level R
Right-channel delay signal level
10. Delay Pan R
Right-channel delay signal output pan
11. Freedback R
Right-channel delay signal feedback volume
12. CrossFB RtoL
Right-channel feedback signal send volume to left input
13. Dir Level R
Right-channel direct signal level
Preset List
No Preset Name
00 Sterao Delay
01 Doubling
02 Short Delay
03 Cross Short Delay
04 Cross Delay
05 Pan L To R
06 Pan R To L
07 Stereo Single Delay
08 Sterao Thin Delay
4.8.6.25 Stereo Tap Delay
Specifications
TypeID
FXID_STTDEL = 0B02H
Available Part
DSP
I/O
2/2
Parameter List
ParaID
Parameter
Bit*Len
Value-Range
Value-Meaning
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
0000
Fx Name
7*16
20H - 7EH
-
0001
Bypass
1
0 - 1
0...Bypass
1...Effect
0002
Delay Time L1
7
0 - 127
0 - 127
0003
Delay Level L1
7
0 - 127
0 - 127
0004
Delay Pan L1
7
0 - 127
0 - 127
0005
Delay Time L2
7
0 - 127
0 - 127
0006
Delay Level L2
7
0 - 127
0 - 127
0007
Delay Pan L2
7
0 - 127
0 - 127
0008
Delay Time FBL
7
0 - 127
0 - 127
0009
Freedback L
7
0 - 127
0 - 127
000A
CrossFB LtoR
7
0 - 127
0 - 127
000B
Dir Level L
7
0 - 127
0 - 127
000C
Delay Time R1
7
0 - 127
0 - 127
000D
Delay Level R1
7
0 - 127
0 - 127
000E
Delay Pan R1
7
0 - 127
0 - 127
000F
Delay Time R2
7
0 - 127
0 - 127
0010
Delay Level R2
7
0 - 127
0 - 127
0011
Delay Pan R2
7
0 - 127
0 - 127
0012
Delay Time FBR
7
0 - 127
0 - 127
0013
Freedback R
7
0 - 127
0 - 127
0014
CrossFB RtoL
7
0 - 127
0 - 127
0015
Dir Level R
7
0 - 127
0 - 127
Operation
This effector provides two-channel stereo delay. There are three taps for each channel, one of
which is used exclusively for feedback. Cross feedback is available for each line feedback.
Delay L
--->---------------+---+===============
+--+----+--+----> Left
L2
+----------- -- --->
+<------------ ---+<----+
+------------------- -- ---- ->
FB L1
Cross FB
FB R1
<--+<-----+ +---------------- ->
+------->
R2
--->+------------------+===============
+--+----+--+----> Right
Delay R
1.
Bypass
Effector function enable/disable. Selecting bypass causes the input signal to be output as-is.
2.
Delay Time L1
Left-channel 1 delay time
3.
Delay Level L1
Left-channel 1 delay signal level
4.
Delay Pan L1
Left-channel 1 delay signal output pan
5.
Delay Time L2
Left-channel 2 delay time
6.
Delay Level L2
Left-channel 2 dealy signal level
7.
Delay Pan L2
Left-channel 2 delay signal output pan
8.
Delay Time FBL
Left-channel feedback delay time
9.
Freedback L
Left-channel delay signal feedback volume
10. CrossFB LtoR
Left-channel feedback signal send volume to right input
11. Dir Level L
Left-channel direct signal level
12. Delay Time R1
Right-channel 1 delay time
13. Delay Level R1
Right-channel 1 delay signal level
14. Delay Pan R1
Right-channel 1 delay signal output pan
15. Delay Time R2
Right-channel 2 delay time
16. Delay Level R2
Right-channel 2 delay signal level
17. Delay Pan R2
Right signal 2 delay signal output pan
18. Delay Time FBL
Right-channel feedback delay time
19. Freedback R
Right-channel delay signal feedback volume
20. CrossFB RotL
Right-channel feedback signal
Right-channel feedback signal send volume to left input
21. Dir Level R
Right-channel direct signal level
Preset List
No Preset Name
00 Stereo Tap Delay1
01 Stereo Tap Delay2
02 Stereo Tap Delay3
03 Single Tap Delay
04 Ambience1
05 Ambience2
06 Ambience3
