25
MZ-2000 MIDI Implementation
0150 EqHighFreq 2 0H - 3H 0H
EQ High Frequency
Specifies cutoff frequency of the high shelving equalizer.
0H : 2 (KHz)
1H : 4 (KHz)
2H : 8 (KHz)
3H : 16 (KHz)
0151 EqHighGain 4 00H - 0CH 06H
EQ High Gain
Gain of the high shelving equalizer
0H : -6 (dB)
6H : 0 (dB)
CH : +6 (dB)
4.4.4.10 Example Settings
Example 1: To the Patch Common Master Key Shift setting to 3
Header Block (Hexadecimal)
00 F0 [System Exclusive Status]
01 44 [Manufacturer's ID] 44H = CASIO ID
02 7E [Model ID MSB] MZ-2000 Sound System Model-ID MSB
03 02 [Model ID LSB] MZ-2000 Sound System Model-ID LSB
04 00 [Message Version]
05 10 SysEx Device Id
Data Block
06 40 tt :Message Type
07 20 d0[0] :Message Id
08 01 d0[1] :CAT PATCH
09 00 d0[2] :Type Id LSB : **00H
10 00 d0[3] :Type Id MSB : 00**H
11 00 d0[4] :MdevId LSB :
12 2F d0[5] :MdevId MSB :
13 00 d0[6] :Section Number LSB
14 00 d0[7] :Section Number MSB
15 00 d0[8] :Parameter Set Number LSB
16 00 d0[9] :Parameter Set Number MSB
17 11 d0[10] :Parameter ID LSB
18 00 d0[11] :Parameter ID :
19 08 d0[12] :Parameter ID MSB & Block Number & Array Flag
20 00 d1[0] :Main Block
21 00 d1[1] :Tg Block
22 00 d1[2] :Common Block
23 07 d3[0] :Number of Data Bit - 1
24 03 d4[0] :Data LSB
25 00 d4[1] :Data MSB
EOX
26 F7 [EOX]
Example 2: To set the Part 2 Receive Channe to 05H (Channel 6)
Header Block (Hexadecimal)
00 F0 [System Exclusive Status]
01 44 [Manufacturer's ID] 44H = CASIO ID
02 7E [Model ID MSB] MZ-2000 Sound System Model-ID MSB
03 02 [Model ID LSB] MZ-2000 Sound System Model-ID LSB
04 00 [Message Version]
05 10 SysEx Device Id
Data Block
06 40 tt :Message Type
07 20 d0[0] :Message Id
08 01 d0[1] :CAT PATCH
09 00 d0[2] :Type Id LSB : **00H
10 00 d0[3] :Type Id MSB : 00**H
11 00 d0[4] :MdevId LSB :
12 2F d0[5] :MdevId MSB :
13 00 d0[6] :Section Number LSB
14 00 d0[7] :Section Number MSB
15 00 d0[8] :Parameter Set Number LSB
16 00 d0[9] :Parameter Set Number MSB
17 18 d0[10] :Parameter ID LSB
18 00 d0[11] :Parameter ID :
19 08 d0[12] :Parameter ID MSB & Block Number & Array Flag
20 00 d1[0] :I:Main Block
21 00 d1[1] :J:Tg Block
22 02 d1[2] :K:Patch Block( Part 2 )
23 04 d3[0] :Number of Data Bit - 1
24 05 d4[0] :Data LSB
EOX
25 F7 [EOX]
Example: To Part 7 Scale Tune D#,E,F,F# to 1,2,3,4¢ respectively. This is an example of setting
the Array Flag.
Header Block (Hexadecimal)
00 F0 [System Exclusive Status]
01 44 [Manufacturer's ID] 44H = CASIO ID
02 7E [Model ID MSB] MZ-2000 Sound System Model-ID MSB
03 02 [Model ID LSB] MZ-2000 Sound System Model-ID LSB
04 00 [Message Version]
05 10 SysEx Device Id
Data Block
06 40 tt :Message Type
07 20 d0[0] :Message Id
08 01 d0[1] :CAT PATCH
09 00 d0[2] :Type Id LSB : **00H
10 00 d0[3] :Type Id MSB : 00**H
11 00 d0[4] :MdevId LSB :
12 2F d0[5] :MdevId MSB :
13 00 d0[6] :Section Number LSB
14 00 d0[7] :Section Number MSB
15 00 d0[8] :Parameter Set Number LSB
16 00 d0[9] :Parameter Set Number MSB
17 77 d0[10] :Parameter ID LSB
18 00 d0[11] :Parameter ID :
19 48 d0[12] :Parameter ID MSB & Block Number & Array Flag
20 00 d1[0] :I:Main Block
21 00 d1[1] :J:Tg Block
22 07 d1[2] :K:Patch Block( Part 7 )
23 00 d2[0] :o:top index number of array to send (MSB)
24 03 d2[1] :p:top index number of array to send (LSB)
25 04 d2[2] :q:number of array member to send
26 07 d3[0] :Number of Data Bit - 1
27 01 d4[0] :Data LSB : D# 1¢
28 00 d4[1] :Data MSB : D# 1¢
29 02 d4[0] :Data LSB : E 2¢
30 00 d4[1] :Data MSB : E 2¢
31 03 d4[0] :Data LSB : F 3¢
32 00 d4[1] :Data MSB : F 3¢
33 04 d4[0] :Data LSB : F# 4¢
34 00 d4[1] :Data MSB : F# 4¢
EOX
35 F7 [EOX]
4.5 Selecting Patch Effects
4.5.1 General
These parameters are used to select individual effect modules. When selecting an effect, you can
specify effect preset data by sending the following three parameters.
* Memory Device ID = 2F00H (Fixed value)
* TypeID =Assigned effect type (See "4.8 Effects.")
* Number = Assigned effect number (See "4.8 Effects.")
