MZ-2000 MIDI Implementation
Operation
This effector allows system-wide chorus settings.
1. Bypass
Effector function enable/disable. Selecting bypass causes the input signal to be output as-is.
2. Hi-Damp
High-range damping characteristics
3. Cho Level
Effect tone level
4. Cho FB
Chorus effect feedback level. A more characteristic sound is produced when this value is
greater.
5. Delay
Delay time used as a reference.
6. Rate
LFO rate
7. Depth
LFO modulation
8. SendTenumerate
Send level to the System Reverb output for this effector.
Preset List
No Preset Name
00 Chorus 1
01 Chorus 2
02 Chorus 3
03 Chorus 4
04 Fbk Chorus
05 Flanger 1
06 Short Delay
07 FB Short Delay
08 Chorus 5
09 Chorus 6
10 Chorus 7
11 Ensemble 1
12 Ensemble 2
13 Ensemble 3
14 Flanger 2
15 Flanger 3
16 Flanger 4
17 Organ 1
18 Organ 2
19 Organ 3
4.8.6.22 Flanger
Specifications
TypeID FXID_FL = 0910H
Available Part DSP
I/O 1/2
Parameter List
ParaID Parameter Bit*Len Value-Range Value-Meaning
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
0000 Fx Name 7*16 20H - 7EH -
0001 Bypass 1 0 - 1 0...Bypass
1...Effect
0002 Manual 7 0 - 127 0 - 127
0003 Feedback 7 0 - 64 -127 -64 - 0 - +63
0004 Depth 7 0 - 127 0 - 127
0005 Rate 7 0 - 127 0 - 127
0006 Waveform 3 0 - 4 0...Sin
1...Tri
2...SawUp
3...SawDw
4...Squ
0007 Step 7 0 - 127 0 - 127
0006 Delay Level 7 0 - 127 0 - 127
Operation
This effector produces a comb filter effect by applying a delay to the input signal and then mixing
the signal with the direct tone to produce distortion. The delay time is modulated by an LFO.
1. Bypass
Effector function enable/disable. Selecting bypass causes the input signal to be output as-is.
2. Manual
Allows manual setting of the reference delay time
3. Feedback
Delay feedback volume. The greater this value, the more distinctive the tone.
4. Depth
LFO modulation
5. Rate
LFO rate
6. Waveform
LFO waveform
o Sin......Sine wave
o SawUp....Sawtooth wave (rising)
o SawDw....Sawtooth wave (falling)
o Squ......Square wave
7. Step
LFO continuity. A value of 0 specifies smooth change, while a larger value specifies coarser
change.
8. Delay Level
Delay signal output level
Preset List
No Preset Name
00 Flanger 1
01 Flanger 2
02 Flanger 3
03 Flanger 4
04 Jet Flanger 1
05 Jet Flanger 2
06 Step Flanger 1
07 Step Flanger 2
08 Flanger 5
09 Flanger 6
10 Flanger 7
11 Flanger 8
4.8.6.23 Delay
Specifications
TypeID FXID_DEL = 0B00H
Available Part DSP
I/O 1/2
Parameter List
ParaID Parameter Bit*Len Value-Range Value-Meaning
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
0000 Fx Name 7*16 20H - 7EH -
0001 Bypass 1 0 - 1 0...Bypass
1...Effect
0002 DlyPre-LPF 7 0 - 7 0 - 7
0003 DlyTimeCnt 7 0 - 127 0 - 127 (0.1ms - 1.0s)
0004 DlyTimeLft 7 0 - 127 0 - 127 (0.1ms - 1.0s)
0005 DlyTimeRit 7 0 - 127 0 - 127 (0.1ms - 1.0s)
0006 DlyLevelCnt 7 0 - 127 0 - 127
0007 DlyLevelLft 7 0 - 127 0 - 127
0008 DlyLevelRit 7 0 - 127 0 - 127
0009 DlyLevel 7 0 - 127 0 - 127
000A DlyFeedback 7 0 - 127 0 - 127
