39
MZ-2000 MIDI Implementation
Operation
This effector is a two-channel left-right input version of Phaser. Its operations and parameters are
identical to those of Phaser. Parameter operations are identical for the left and right channels.
Preset List
No Preset Name
00 Phaser 1
01 Phaser 2
02 Phaser 3
03 Phaser 4
04 Step1
05 Step2
4.8.6.19 Chorus
Specifications
TypeID FXID_CHO = 0900H
Available Part DSP
I/O 1/2
Parameter List
ParaID Parameter Bit*Len Value-Range Value-Meaning
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
0000 Fx Name 7*16 20H - 7EH -
0001 Bypass 1 0 - 1 0...Bypass
1...Effect
0002 Delay 7 0 - 127
0003 Depth 7 0 - 127
0004 Rate 7 0 - 127
0005 DelayLevel 7 0 - 127
Operation
This effector provides depth and breadth by delaying the input signal, modulating the pitch of the
input signal by adjusting the delay time with an LFO, and then mixing the signal with the direct
tone.
1. Bypass
Effector function enable/disable. Selecting bypass causes the input signal to be output as-is.
2. Delay
Delay time used as a reference.
3. Depth
LFO modulation
4. Rate
LFO rate
5. DelayLevel
Delay signal output level.
Preset List
No Preset Name
00 Chorus 1
01 Chorus 2
02 Chorus 3
03 Chorus 4
04 Chorus 5
05 Chorus 6
06 Fbk Chorus 1
07 Fbk Chorus 2
08 Mod. Delay 1
09 Mod. Delay 2
10 Chorus 7
11 Chorus 8
12 Chorus 9
13 Chorus 10
14 Chorus 11
15 Chorus 12
16 Chorus 13
4.8.6.20 Stereo Chorus
Specifications
TypeID FXID_STCHO = 0901H
Available Part DSP
I/O 2/2
Parameter List
ParaID Parameter Bit*Len Value-Range Value-Meaning
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
0000 Fx Name 7*16 20H - 7EH -
0001 Bypass 1 0 - 1 0...Bypass
1...Effect
0002 Delay 7 0 - 127 0 - 127
0003 Depth 7 0 - 127 0 - 127
0004 Rate 7 0 - 127 0 - 127
0005 CrossLevel 7 0 - 127 0 - 127
0006 DelayLevel 7 0 - 127 0 - 127
Operation
This effector is basically identical to Chorus, except that it is capabile of two-channel stereo delay.
1. Bypass
Effector function enable/disable. Selecting bypass causes the input signal to be output as-is.
2. Delay
Delay time used as a reference.
3. Depth
LFO modulation
4. Rate
LFO rate
5. CrossLevel
Send volume of the left-right delay signal to the opposite output, which has an influence on
the nuances of the effect.
6. DelayLevel
Delay signal output level.
Preset List
No Preset Name
00 Stereo Chorus 1
01 Stereo Chorus 2
02 Stereo Chorus 3
03 Stereo Deep Chorus 1
04 Stereo Deep Chorus 2
05 Stereo Fbk Chorus
06 Stereo Flanger 1
07 Stereo Flanger 2
4.8.6.21 System Chorus
Specifications
TypeID FXID_SYCHO = 0902H
Available Part System Chorus
I/O 1/2
Parameter List
ParaID Parameter Bit*Len Value-Range Value-Meaning
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
0000 Fx Name 7*16 20H - 7EH -
0001 Bypass 1 0 - 1 0...Bypass
1...Effect
0002 Hi-Damp 7 0 - 127 0 - 127
0003 Cho Level 7 0 - 127 0 - 127
0004 Cho FB 7 0 - 127 0 - 127
0005 Delay 7 0 - 127 0 - 127
0006 Rate 7 0 - 127 0 - 127
0007 Depth 7 0 - 127 0 - 127
0008 SendToRev 7 0 - 127 0 - 127
