MZ-2000 MIDI Implementation
Operation
This effector controls tone quality. Settings can be made for three individual bands, and the mid-
range parametric equalizer provides great latitude for sound creation.
1.
Bypass
Effector function enable/disable. Selecting bypass causes the input signal to be output as-is.
2.
Lo Freq
Low-range equalizer trigger frequency
3.
Lo Gain
Low-range level
4.
Mid Freq
Mid-range equalizer center trigger freqency
5.
Mid Gain
Mid-range level
6.
Mid Peak
Mid-range equalizer frequency range. A larger value defines a narrower range.
7.
Hi Freq
High-range equalizer trigger frequency
8.
Hi Gain
High-range level
9.
Level
Output level
Equalizer Frequencies
The following shows the relationships between equalizer frequency parameter values and actual
frequencies.
Freq: Frequency
Value: Parameter Value
cc
value Freq
value Freq
value
Freq
value Freq
value Freq
value Freq
0
20
10
63
20
200
30
630
40
2.0K
50
6.3K
1
22
11
70
21
225
31
700
41
2.3K
51
7.0K
2
25
12
80
22
250
32
800
42
2.5K
52
8.0K
3
28
13
90
23
280
33
900
43
2.8K
53
9.0K
4
32
14
100
24
315
34
1.0K
44
3.2K
54
10.0K
5
36
15
110
25
355
35
1.1K
45
3.6K
55
11.0K
6
40
16
125
26
400
36
1.2K
46
4.0K
56
12.0K
7
45
17
140
27
455
37
1.4K
47
4.5K
57
14.0K
8
50
18
160
28
500
38
1.6K
48
5.0K
58
16.0K
9
56
19
180
29
560
39
1.8K
49
5.6K
59
18.0K
60
20.0K
Preset List
No 3Band EQ
00 Low Boost
01 High Boost
02 High-Low
03 HiCut-MidBoost
04 HiCut-MidBoost2
05 Loudness1
06 LoudLo1
07 LoudHi1
08 Loudness2
09 LoudLo2
10 LoudHi2
11 Loud3
12 Loud3 Lo+
13 Loud3 Hi+
14 AntiFeedback
15 Flat
16 LoCut1
17 LoCut2
4.8.6.9 Stereo 3-Band EQ
Specifications
TypeID
FXID_ST3BEQ = 0201H
Available Part
DSP, Master
I/O
2/2
Parameter List
ParaID
Parameter
Bit*Len
Value-Range
Value-Meaning
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
0000
Fx Name
7*16
20H - 7EH
-
0001
Bypass
1
0 - 1
0...Bypass
1...Effect
0002
Lo Freq
7
8 - 40
50 - 2.0K(Hz) *Note1
0003
Lo Gain
7
52 - 64 - 76
-12dB - 0dB - +12dB
0004
Mid Freq
7
14 - 54
100 - 10K(Hz) *Note1
0005
Mid Gain
7
46 - 64 - 82
-18dB - 0dB - +18dB
0006
Mid Peak
7
10 - 120
1.0 - 12.0 (Q)
0007
Hi Freq
7
28 - 58
500 - 16.0K(Hz) *Note1
0008
Hi Gain
7
52 - 64 - 76
-12dB - 0dB - +12dB
0009
Level
7
0 - 127
0 - 127
Operation
This effector is a 2-channel, left/right input version of 3-band EQ. Its operations and parameters
are identical tothose of 3-Band EQ. Parameter operations are identical for the left and right chan-
nels.
Preset List
No Preset Name
00 Lo+
01 Hi+
02 LoHi+Mid-
03 Mid+
04 Mid-
05 Hi-
06 Lo-
07 LoHi-Mid+
08 Loud1
09 Loud1 Lo+
10 Loud1 Hi+
11 Loud2
12 Loud2 Lo+
13 Loud2 Hi+
14 Loud3
15 Loud3 Lo+
16 Loud3 Hi+
17 Flat
4.8.6.10 Enhancer
Specifications
TypeID
FXID_ENH = 0204H
Available Part
DSP
I/O
1/1
ParaID
Parameter
Bit*Len
Value-Range
Value-Meaning
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
0000
Fx Name
7*16
20H - 7EH
-
0001
Bypass
1
0 - 1
0...Bypass
1...Effect
0002
Lo
7
0 - 64 -127
-64 - 0 - +63
0003
Hi
7
0 - 64 -127
-64 - 0 - +63
0004
Level
7
0 - 127
0 - 127
