48
MZ-2000 MIDI Implementation
4.9.2.2 Mix Parameter Set Bulk Dump
The Mix Parameter Set can be sent and received using bulk dump. There are two protocols, One-
Way and Handshake, which are the same as those described under "4.1 MZ-2000 Sound Source
Common System Exclusive Format."
The following shows the section that applies to Mix only.
tt 0100aaaa aaaa = BDS..."SYSEX_ACT_BDS" = 02H
BDR..."SYSEX_ACT_BDR" = 03H
HDS..."SYSEX_ACT_HDS" = 04H
HDR..."SYSEX_ACT_HDR" = 05H
HDA..."SYSEX_ACT_HDA" = 06H
HDJ..."SYSEX_ACT_HDJ" = 07H
HDE..."SYSEX_ACT_HDE" = 08H
d0[0] 0ooocccc cccc = Parameter Set Category = MIX = 04H
ooo = 00H
d0[1] 0ttttttt 0TTTTTTT0ttttttt = Type ID = 0000 Fixed
d0[2] 0TTTTTTT
d0[3] 0mmmmmmm 0MMMMMMM0mmmmmmm = Mdev ID = Internal RAM = 2F00 Fixed
d0[4] 0MMMMMMM
d0[5] 0sssssss 00SSSSSSSsssssss = Section Number = 0000 Fixed
d0[6] 0SSSSSSS
d0[7] 0nnnnnnn 00NNNNNNNnnnnnnn = PS Number = 0000 Fixed
d0[8] 0NNNNNNN
The volume of data that follows the above is very large, so it is not included here. This data can be
looked up by sending HDR and BDR.
4.10 Drum Setup
4.10.1 Drum Setup Parameter Control Message Format
tt 0100aaaa aaaa = IPC..."SYSEX_ACT_IPC" (00H)
IPR..."SYSEX_ACT_IPR" (01H)
d0[0] 00100000 20H : Parmeter Modify Message-ID
d0[1] 0000cccc cccc = Category = CAT_SUB (05H)
d0[2] 0ttttttt 0TTTTTTT0ttttttt = Type ID
= Target operation Sub Type ID = 05H
d0[3] 0TTTTTTT
d0[4] 0mmmmmmm 0MMMMMMM0mmmmmmm = MDEV ID = 2F00H
d0[5] 0MMMMMMM
d0[6] 0sssssss 0SSSSSSS0sssssss = Section Number = 0000H Fixed
d0[7] 0SSSSSSS
d0[8] 0nnnnnnn 00NNNNNNNnnnnnnn = PS Number = 00H -- 03H
d0[9] 0NNNNNNN
The Parameter Set Number specified here is a Map number.
0 = Map1, 1 = Map2, 2 = Map3, 3 = Map4
d0[10] 0ppppppp qqPPPPPPPppppppp = Parameter ID = 01H -- 08H
d0[11] 0PPPPPPP
For details, see "4.10.1.1 Drum Setup Parameter ID and Value
Range."
d0[12] 0rbbbbqq bbbb = number of parameter block - 1 = 01H
r = array flag = 0
d1[0] 0iiiiiii 0iiiiiii = I:Main Block = 0
d1[1] 0jjjjjjj 0jjjjjjj = J:Setup Block= 0 to 127
Specifies the Drum Part Note Number.
✩ One data size (number of bits) minus 1
d3[0] 000zzzzz
zzzzz = number of bits - 1
When zzzz + 1 is: The number of data bytes is:
1 to 7 1
8 to 14 2
15 to 21 3
22 to 28 4
29 to 35 5
✩ Parameter Values
7 bits or less
d4[0] 0xxxxxxx xxxxxxx = Data
4.10.1.1 Drum Setup ParameterID and Value Range
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
ParaID Parameter Bit Value default Description
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
0001 PlayNoteNum 7 00H - 7FH -- Pitch coarse
0002 Level 7 00H - 7FH -- Instrument TVA Level
0003 AssignGrp 7 00H - 7FH -- Group Number(0:Non,1--127)
0004 Pan 7 00H - 7FH -- -64(RANDOM)
-63(LEFT),+63(RIGHT)
0005 RevSendLevel 7 00H - 7FH -- Reverb Send Level
0006 RxNoteOff 1 00H - 01H -- 0:Off, 1:On
0007 ChoSendLevel 7 00H - 7FH -- Chorus Send Level
0008 RxNoteOn 1 00H - 01H -- 0:Off, 1:On
4.10.1.2 Setup Example
Example: Drum Setup Map2, KeyNumber=60(C4), Level=127
Header Block (Hexadecimal)
No. Data
00 F0 [System Exclusive Status]
01 44 [Manufacturer's ID] 44H = CASIO ID
02 7E [Model ID MSB] MZ-2000 Sound System Model-ID MSB
03 02 [Model ID LSB] MZ-2000 Sound System Model-ID LSB
04 00 [Message Version]
05 10 SysEx Device Id
Data Block
No. Data
06 40 tt :Message Type
07 20 d0[0] :Message Id
08 05 d0[1] :CAT CAT_SUB
09 05 d0[2] :Type Id LSB : **05H
10 00 d0[3] :Type Id MSB : 00**H
11 00 d0[4] :MdevId LSB :
12 2F d0[5] :MdevId MSB :
13 00 d0[6] :Section Number LSB
14 00 d0[7] :Section Number MSB
15 01 d0[8] :Parameter Set Number LSB ( Map2 = **01H )
16 00 d0[9] :Parameter Set Number MSB ( Map2 = 00**H )
17 02 d0[10] :Parameter ID LSB ( Level ParameterID = 2 )
18 00 d0[11] :Parameter ID :
19 04 d0[12] :Parameter ID MSB & Block Number & Array Flag
20 00 d1[0] :Main Block
21 3C d1[1] :Setup Block ( 3CH = KeyNumber 60 )
22 06 d3[0] :Number of Data bit - 1 (Data number of bits = 7)
23 7F d4[0] :Data LSB ( Level = 127 )
EOX
No. Data
24 F7 [EOX]
