MZ-2000 MIDI Implementation

Receive

When the MZ-2000 receives the Vibrato Delay message, the reset vibrato delay value for the tone

is changed accordingly. There is no change when the value of the data entry MSB is 40H (0).

Send

The Vibrato Delay message cannot be sent.

2.3.20.4 TVF Cutoff Frequency

NRPN MSB = 01H

NRPN LSB = 20H

Data Entry MSB = mmH

mm : Cutoff Frequency = 00H to 40H to 7FH (-64 to 0 to +63)

Receive

When the MZ-2000 receives the TVF Cutoff Frequency message, the reset TVF cutoff frequency

value for the tone is changed accordingly. There is no change when the value of the data entry

MSB is 40H (0).

Send

The TVF Cutoff Frequency message is sent whenever a cutoff frequency operation is performed

using the initial screen in the Synthesizer Mode.

2.3.20.5 TVF Resonance

NRPN MSB = 01H

NRPN LSB = 21H

Data Entry MSB = mmH

mm : TVF Resonance = 00H to 40H to 7FH (-64 to 0 to +63)

Receive

When the MZ-2000 receives the TVF Resonance message, the reset TVF resonance value for the

tone is changed accordingly. There is no change when the value of the data entry MSB is 40H (0).

Send

The TVF Cutoff Frequency message is sent whenever a resonance operation is performed using

the initial screen in the Synthesizer Mode.

2.3.20.6 TVF/TVA Envelope Attack Time

NRPN MSB = 01H

NRPN LSB = 63H

Data Entry MSB = mmH

mm : TVF/TVA Envelope Attack Time = 00H to 40H to 7FH (-64 to 0 to +63)

Receive

When the MZ-2000 receives the TVF/TVA Envelope Attack Time message, the reset TVF/TVA

envelope attack time value for the tone is changed accordingly. There is no change when the value

of the data entry MSB is 40H (0).

Send

The TVF/TVA Envelope Attack Time message is sent whenever an attack time operation is per-

formed using the initial screen in the Synthesizer Mode.

2.3.20.7 TVF/TVA Envelope Decay Time

NRPN MSB = 01H

NRPN LSB = 64H

Data Entry MSB = mmH

mm : TVF/TVA Envelope Decay Time = 00H to 40H to 7FH (-64 to 0 to +63)

Receive

When the MZ-2000 receives the TVF/TVA Envelope Decay Time message, the reset TVF/TVA

envelope decay time value for the tone is changed accordingly.

There is no change when the value of the data entry MSB is 40H (0).

Send

The TVF/TVA Envelope Decay Time message cannot be sent.

2.3.20.8 TVF/TVA Envelope Release Time

NRPN MSB = 01H

NRPN LSB = 66H

Data Entry MSB = mmH

mm : TVF/TVA Envelope Release Time = 00H to 40H to 7FH (-64 to 0 to +63)

Receive

When the MZ-2000 receives the TVF/TVA Envelope Release Time message, the reset TVF/TVA

envelope release time value for the tone is changed accordingly.

There is no change when the value of the data entry MSB is 40H (0).

Send

The TVF/TVA Envelope Release Time message is sent whenever whenever a release time opera-

tion is performed using the initial screen in the Synthesizer Mode.

2.3.20.9 Drawbar Control

NRPN MSB = 40H

NRPN LSB = 00H to 08H (16' to 1')

Data Entry MSB = mmH

mm : Bar Position = 00H to 7FH (0 to 8)

The following shows the relationship between the NRPN and the drawbar numbers.

MSB

LSB

Drawbar Number

40H

00H

16'

40H

01H

5 1/3'

40H

02H

8'

40H

03H

4'

40H

04H

2 1/3'

40H

05H

2'

40H

06H

1 3/5'

40H

07H

1 1/3'

40H

08H

1'

The following shows the drawbar position for each mm value.

mm : Bar Position

00H to 0EH

0

0FH to 1CH

1

1DH to 2AH

2

2BH to 38H

3

39H to 47H

4

48H to 55H

5

56H to 63H

6

64H to 71H

7

72H to 7FH

8

Receive

While a Preset Drawbar Organ tone (Bank Number 60H) or User Drawbar Organ (Bank Number

61H) is selected on the MZ-2000, you can use Drawbar Control messages for external adjustment

of harmonic component levels.
