Assembly of the front and rear shock absorber – OFNA Racing Ultra LX Comp User Manual
Page 25
35313
3mm
Nylon Nut
40056
Plastic
bushing
* Take the plastic bushing
from the shock plastic
parts tree.
3x20mm
Cap Screw
ASSEMBLY OF THE FRONT AND REAR SHOCK ABSORBER
35313
3mm
Nylon Nut
40056
Plastic
bushing
3x20mm
Cap Screw
35313
M3 Nylon Nut
X4
X4
3X20mm
Cap Screw
Assembly of the right and left hand side
are the same.
Assembly of the right and left hand side
are the same.
Assembly of the right and left hand side
are the same.
