OFNA Racing Ultra LX Comp User Manual
Page 18
36100
Center Drive
Shaft (Rear)
94027
4x16mm
Flat Head
Hex Screw
94023
3x25mm
Flat Head
Hex Screw
94027
4x16mm
Flat Head
Hex Screw
34080
Stone Guard
34080
Stone Guide
94019
3x10mm
Flat Head
Hex Screw
94027
4x16mm
Flat Head Hex Screw
X4
94023
3x25mm
Flat Head Hex Screw
X2
94019
3x10mm
Flat Head Hex Screw
X6
94019
3x10mm
Flat Head
Hex Screw
94019
3x10mm
Flat Head
Hex Screw
94019
3x10mm
Flat Head
Hex Screw
94019
3x10mm
Flat Head
Hex Screw
94019
3x10mm
Flat Head
Hex Screw
*Insert drive shaft into
cap joint before assembly.
ASSEMBLY OF THEREAR BOX ONTO CHASSIS
ASSEMBLY OF THE STONE GUARD
34041
Chassis
