Assembly of the radio tray onto chassis – OFNA Racing Ultra LX Comp User Manual
Page 20
34070
Rear Stiffener
30287
Fuel Tank
Plastic Post
30287
Fuel Tank
Plastic Post
Pressure Nipple
X7
94019
3x10mm
Flat Head Hex
Screw
94003
3x10mm
Flat Head Hex
Screw
94003
3X10mm
Hex Screw
X4
94003
3X10mm
Hex Screw
94003
3X10mm
Hex Screw
94019
3x10mm
Flat Head Hex
Screw
94019
3x10mm
Flat Head Hex
Screw
94004
3X12mm
Hex Screw
94004
X12mm
Hex Screw
94004
3X12mm
Hex Screw
X2
40109
Fuel Tank
40109
Fuel Tank
Pressure Nipple
ASSEMBLY OF THE RADIO TRAY ONTO CHASSIS
