Page 10

40104
10mm
Ball and Socket

36860
5x35mm
Turnbuckle

36860
5x35mm

90026
Set Screw

36055
2.5x16.8mm
Pin

36053
8x16x5mm
Ball bearings

36054
Wheel Hub

36053
8x16x5mm
Ballbearings

36053
8x16x5mm
Ball bearings

34022
CVA Joint

40102
Front
Lower Arm-R

40102
Front
Lower Arm-L

90026
5x5mm Set Screw

36055
2.5x16.8mm Pin

ASSEMBLY OF THE FRONT UPPER ARMS

40101
Front Upper
Arm Ball End

40101
Front Upper
Arm (Right)

40101
Front Upper
Arm (Left)

* Leave 6mm .

Assembly of the right and left hand side
are the same.

* "L" mark are for left side.

ASSEMBLY OF THE FRONT KNUCKLE ARMS

40103
Front Knuckle
Arm(Right)

40103
Front Knuckle
Arm(Left)

ASSEMBLY OF THE FRONT LOWER ARMS

* Notice the direction.

40104
10mm
Steering Ball

Note:

36053
8x16x5mm
Ball bearings

34024
CVA Axle

34023
CVA Bone
