OFNA Racing Ultra LX Comp - Manual (Page 15)

94022
3x18mm
Flat Head Hex Screw
94023
3x20mm
Flat Head Hex Screw
x2
35313
M3 Nylon Nut x2
X2
30270
Wing Mount
(Left) Kit
30270
Wing Mount
(Right) Kit
10290
3mm Alum.
Washer
10290
3mm Alum.
Washer
10290
3mm Alum. Washer x6
94022
M3x18mm
Flat Head
Hex Screw
94022
M3x18mm
Flat Head
Hex Screw
94023
M3x20mm
Flat Head
Hex Screw
94023
M3x20mm
Flat Head
Hex Screw
30270
Wing Stay
Post
(Plastic)
35313
M3 Nylon Nut
94011
4X16mm
Hex Screw X2
94011
4X16mm
Hex Screw
90019
3X25mm
Cap Screw x2
1. (High Position) 2. (Low Position) 3. (Bigger Angle)
* The installing angle becomes bigger in order 1 to 3.
3x8x0.8mm
Washer x2
3x8mm Hex Screw x2
3x18mm
Washer
3x8mm
Hex Screw
3x8x0.8mm
Washer
M3x3
Set Screw
30401
Stabilizer
Ball End
30340
Stabilizer Ball
30401
6mm Ball 30401
Stabilizer
Ball End
94035
M3x8mm
Set Screw
ASSEMBLY OF THE
REAR STABILIZER ASSEMBLY OF THE
STABILIZER ROD
30340
Stabilizer
A B
* Cut the plastic as shown.
90019
3x25mm
Cap Screw
Stabilizer Rod
Assembly
30271
Wing Holder
Assembly
ASSEMBLY OF THE WING STAY
30271
Wing Holder
Assembly
30271
Wing Holder
Assembly
