OFNA Racing Ultra LX Comp - Manual (Page 14)

30151
4mm
Arm Shaft
34028
Rear
Driver Shaft
90021
3.0mm
E-Ring
2.5mm
E-Ring
90020
2.5mm
E-Ring
90021
3.0mm
E-Ring
40102
Rear Lower Arm
3mm
Plastic Washer
3mm
Plastic Washer
36170
3mm
Arm Shaft
36081
Wheel
Rear Hub
36053
8x16x5mm
Ball Bearings
36053
8x16x5mm
Ball Bearings
90026
5X4mm
Set Screw
*Do not tighten
set screw over tighten.
X4 90021
3.0mm E-Ring
X4 90020
2.5mm E-Ring
E« ¬ ¦ © А ф
36850
7mm Ball
36850
7mm Ball
36880
5x60mm
Turnbuckle
35313
Nylon Nut
X2 90026
5x5mm
Set screw
94035
M3x8mm Set Screw X2
94033
M3x3 Set Screw X2
94006
3X18mm Hex Screw x2
94006
3X18mm
Hex Screw
35313
M3 Nylon Nut X2
35313
Nylon Nut
40065
Upper arm
Plastic Rod End
40065
Upper arm
Plastic Rod End
36055
2.5x16.8mm
Pin
36082
Rear Wheel
Axle Shaft
26mm
ASSEMBLY OF THE REAR WHEEL HUB ASSEMBLY OF THE UPPER ARM ROD
*Builds two rear wheel hubs for use.
* Builds two upper arms for left
and right hand-side.
* Anticlockwise mark.
X2
90018
3X25mm
Cap Screw
90018
3X25mm
Cap Screw
ASSEMBLY OF THE REAR LOW ARMS INTO GEAR BOX
0 10 20 30 40 50
mm
Assembly of the right and left hand side
are the same.
Assembly of the right and left hand side
are the same.
* Insert the rear drive shaft
before assembly the rear
lower arm.
36054
Wheel
Hub (8mm)
90020
