OFNA Racing Blazer SST - Manual (Page 7)

Step 1
Step 3
Step 2
ASSEMBLY OF THE
FRONT LOWER ARMS
Assembly of the right and left hand side are the same.
Assembly of the right and left hand side are the same.
Insert the rear drive shaft into
cap joint before assembly
the rear lower arm.
ASSEMBLY OF THE FRONT SUSPENSION ARMS
40023
Lower Arm
Shaft (4mm)
90021
E-Ring
3mm
E-Ring
90021
E-Ring
2.5mm
E-Ring
2.5mm
E-Ring
2.5mm
E-Ring
36170
Arm Shaft
3mm
..........X4
..........X4
..........X4
ASSEMBLY OF THE
FRONT LOWER ARMS
4x16mm
Cap Screw
4x16mm
Cap Screw
4x16mm
Cap Screw
ASSEMBLY OF THE
FRONT KNUCKLE ARMS
CLIP IN THE CASTER ADJUSTER
A
40101
Caster Adjuster
B
A
B
Caster angle will
become bigger. Caster angle will
become less. Caster Adjuster
* Use caster adjuster to change the
caster angle.
90020
40104
90020
40104
40104
90021
90020
