OFNA Racing Blazer SST - Manual (Page 6)

ASSEMBLY OF THE FRONT SHOCK STAY
40116
Shock Tower
4x12mm
Hex Screw
4x12mm
Hex Screw
4x12mm
Hex Screw 3x12mm
Hex Screw
3x12mm
Hex Screw
..........X2
..........X2
S cr
ew
C
em
en
t
S
re c
w e
e
t
C
m
n
ASSEMBLY OF THE KNUCKLE ARMS
"R" for right hand side.
"L" for Left hand side. 36053
8x16x5mm
Ball bearing
36053
8x16x5mm
Ball bearing
36053
8x16x5mm
Ball bearing
40103
Alloy Front
Knuckle Arm
(Right)
40103
Alloy Front
Knuckle Arm
(Left)
40105
8mm CVD Joint
(Front)
40105
8mm CVD Joint
(Front)
36053
8x16x5mm
Ball bearing
36054
Alum.
Wheel Hub 8mm
36054
Alum.
Wheel Hub 8mm
36055
2.5x17mm
Pin
36055
2.5x17mm
Pin
36055
2.5x17mm
Pin
5x4mm
Set Screw
5x4mm
Set Screw
5x4mm
Set Screw
..........X2
..........X2
ASSEMBLY OF THE FRONT UPPER ARMS
36860
5x35mm
Turnbuckle
40101
Front Upper
Arm Ball End
40101
Front Upper
Arm (Left)
40101
Front Upper
Arm (Right)
40101
Front Upper
Arm Ball End
40104
10mm
Ball and Socket
40104
10mm
Ball and Socket
36860
5x35mm
Turnbuckle
¡¯ A p p ro x 6 m m
5x35mmT u rn b u c k le ¡@ ..........X2
ASSEMBLY OF THE FRONT LOWER ARMS
*A 4x10mm set screw is
used to adjust the ride
height.
*A 4x10mm set screw is
used to adjust the ride
height.
40102
Front Lower Arm-L
40102
Front Lower Arm-R
40104
10mm
Ball and Socket
40104
10mm
Ball and Socket
4x10mm
Set Screw
4x10mm
Set Screw
4x10mm
Set Screw
..........X2
94010
94010
94010
94004
94010
36860
90026
90026
90026
36870
36870
36870
