Assembly of the rear suspension arms – OFNA Racing Blazer SST User Manual
Page 11
Step 1
Step 2
Step 3
..........X2
..........X2
..........X2
..........X2
40023
4mm
Lower Arm Shaft
40107
Rear
Driver Shaft
(104mm)
3.0mm
E-Ring
3.0mm
E-Ring
2.5mm
E-Ring
2.5mm
E-Ring
3mm
Plastic Washer
3mm
Plastic Washer
36170
3mm Arm Shaft
M3x3
Set Screw
3X16mm
Cap Screw
3X16mm
Cap Screw
M3
Nylon Nut
35313
Nylon Nut
35313
Nylon Nut
3X25mm
Cap Screw
3X25mm
Cap Screw
*Insert the rear drive shaft
before assembly.
ASSEMBLY OF THE REAR SUSPENSION ARMS
3mm
E-Ring
2.5mm
E-Ring
..........X4
..........X2
Assembly of the right and left hand side are the same.
90021
90021
90020
90020
40102
40102
94007
90018
90021
90020
35313
94007
90018
