Assembly of the tires and wheels – OFNA Racing Blazer SST User Manual
Page 27
Step 1
Step 2
ASSEMBLY OF THE TIRES AND WHEELS
S
N
IN
TA
T
G
L
U
E
Apply instant glue into
the groove of the wheel.
86070
Stadium
Tires
B-21
Inner Sponge
86069
Stadium Wheel
Tire and Wheel
assembly.
Tire and Wheel
assembly.
15072
Blue
Wheel Nut
15072
Blue
Wheel Nut
ASSEMBLY OF THE TIRE ONTO FRONT KNUCKLE AND REAR HUB
Assembly of the right and left hand side are the same.
