Cable Type 2
4 twisted pair unshielded CAT 5, Belden #1583(A, B, E, ENH, R)
4 twisted pair shielded CAT 5, Belden #1624 (P, R)
4 twisted pair unsheilded CAT 5, Belden #1700 (A, R)
Max Distance
for Cable (feet)
Max Distance for
Cable (meters)
Number of
SR 4 Remotes
Vs = 15V
RPM 44
RPM 22
1000 305 1
1000 305 2
1000 305 3
1000 305 4
1000 305 5
1000 305 6
1000 305 7
952 290 8
Vs = 12V
RPM 88
1000 305 1
1000 305 2
1000 305 3
1000 305 4
919 280 5
778 237 6
674 205 7
595 181 8
Vs = 8V 671 205 1
403 123 2
288 88 3
224 68 4
184 56 5
156 47 6
135 41 7
119 36 8
Note: This table is only for systems using SR 4 remotes (all remotes on 485 bus are
the same). For mix and match calculation of SR 2, SR 3 and SR 4 Remotes, use the
SRCABLELENGTH.XLS Microsoft Excel™ spreadsheet on the Drag Net CD-ROM or
at www.rane.com/sr4.html.
Requires
external
supply
